Product Details | ELECTRICAL FREQUENCY METER

6625-00-004-8066 An instrument which measures the rate of regularly recurring variations in an electric current or voltage and is usually calibrated in Hertz (cycles per second or CPS). The value may be expressed by means of a pointer and calibrated dial vibrating reed or a digital read out display. For instruments which measure radio frequencies, see CALIBRATOR, FREQUENCY; and WAVEMENTER. Excludes: COUNTER ELECTRONIC DIGITAL.

Part Alternates: 04306-3004, 267842, 30010, 300-10, 35.7002, 357002, 63716750, 637-16750, 66250048066, 69597, 69-597, 6625-00-004-8066, 00-004-8066, 6625000048066, 043063004, 000048066

Instruments and Laboratory Equipment | Electrical and Electronic Properties Measuring and Testing Instruments

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
66	16 JUN 1972	00-004-8066	16454 ( METER, ELECTRICAL FREQUENCY )
