NSN 6220-01-496-8263 A1439324A, A14393-24A, 01-496-8263
Product Details | ILLUMINATION PANEL
6220-01-496-8263 A glass or plastic panel designed to have photometric requirements and be an integral part of an electrical circuit providing illumination to an indicator assembly. The surface can be treated to react to electrical energy with illumination. Excludes all engraved panels. See PANEL, INDICATING, LIGHT TRANSMITTING.20262100045Indoor and Outdoor Electric Lighting Fixtures62200038Electric Vehicular Lights and Fixtures
Part Alternates: A1439324A, A14393-24A, 6220-01-496-8263, 01-496-8263, 6220014968263, 014968263
Lighting Fixtures and Lamps | Electric Vehicular Lights and Fixtures
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 62 | 29 APR 2002 | 01-496-8263 | 40114 ( PANEL, ILLUMINATION ) |
Demand History | NSN 6220-01-496-8263
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 6220-01-496-8263 | 2013-02-42 | 10 | US |
| 6220-01-496-8263 | 2006-05-140 | 2 | DIBBS |
Cross Reference | NSN 6220-01-496-8263
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| A14393-24A | 6D887 | PAXTON COMPANY |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 6220-01-496-8263
Technical Data | NSN 6220-01-496-8263
| Characteristic | Specifications |
|---|---|
| INDICATOR TYPE | LIGHT |
| AC VOLTAGE RATING | 24.0 VOLTS NOMINAL |
| SPECIAL FEATURES | ILLUMINATION LED; CALLED COMPASS INDICATOR LIGHT |
| III END ITEM IDENTIFICATION | RIB BOAT |
| III USAGE DESIGN | COMPASS ILLUMINATION |
Restrictions/Controls & Freight Information | NSN 6220-01-496-8263
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 017870 | AUTO ASSEMBLIES/DEVICE LIGHT |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 585 | unknown |
| Originating Activity Code | KZ | Defense Supply Center Philadelphia Philadelphia, PA 19101 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 6220-01-496-8263
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
