NSN 6220-01-283-8705 400015, 4002121, 40-02121
Product Details | VEHICULAR STOP LIGHT-TAILLIGHT
6220-01-283-8705 An item which has the dual purpose of a STOP LIGHT, VEHICULAR and TAILLIGHT, VEHICULAR. Includes items which may be used for directional signaling.
Part Alternates: 400015, 4002121, 40-02121, 6220-01-283-8705, 01-283-8705, 6220012838705, 012838705
Lighting Fixtures and Lamps | Electric Vehicular Lights and Fixtures
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 62 | 14 AUG 1988 | 01-283-8705 | 17690 ( STOP LIGHT-TAILLIGHT, VEHICULAR ) |
Drawings & Photos | NSN 6220-01-283-8705
Demand History | NSN 6220-01-283-8705
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 400015 | 2011-10-292 | 4 | US |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 6220-01-283-8705
Technical Data | NSN 6220-01-283-8705
| Characteristic | Specifications |
|---|---|
| SHAPE | ROUND |
| OVERALL DIAMETER | 5.875 INCHES NOMINAL |
| OVERALL LENGTH | ANY ACCEPTABLE |
| VOLTAGE RATING IN VOLTS | 12.0 DC NOMINAL |
| MATERIAL | PLASTIC ACRYLIC BODY PLASTIC ACRYLIC LENS |
| LAMP TYPE ACCOMMODATED AND QUANTITY | 1 INCANDESCENT |
| LAMP BASE TYPE ACCOMMODATED | DOUBLE CONTACT BAYONET CANDELABRA |
| LENS TYPE AND QUANTITY | 1 PLANO CONVEX |
| LENS SURFACE CONDITION | CONCENTRIC RINGS BACK SMOOTH FACE |
| LENS COLOR | RED |
| LENS TRANSPARENCY | TRANSLUCENT |
| MOUNTING METHOD | UNTHREADED HOLE |
| FURNISHED ITEMS AND QUANTITY | 1 LAMP |
| III END ITEM IDENTIFICATION | WATER TRUCK,MODEL A-24 |
Restrictions/Controls & Freight Information | NSN 6220-01-283-8705
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 017870 | AUTO ASSEMBLIES/DEVICE LIGHT |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 586 | unknown |
| Originating Activity Code | CH | Defense Supply Center Richmond Richmond, VA 23297 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
