Product Details | AIRCRAFT COCKPIT LIGHT

6220-00-984-7767 A light specifically designed to be permanently installed in aircraft for map reading or cockpit illumination. It may contain dimming features, switches, filters, and/or cables or coiled cables to permit portability within the length of the cable. If provided with cables or coiled cables, the mounting base must remain fixed to the aircraft and include a snap-in or similar locking device to permit detachment and attachment of the light. For items that supply general illumination for other compartments of an aircraft, see LIGHT, DOME. Excludes LIGHT (1), EXTENSION.

Part Alternates: 1500301, 15-0030-1, 6220-00-984-7767, 00-984-7767, 6220009847767, 009847767

Lighting Fixtures and Lamps | Electric Vehicular Lights and Fixtures

Supply Group (FSG) NSN Assign. NIIN
62 01 JAN 1962 00-984-7767

Demand History | NSN 6220-00-984-7767

Part Number Request Date QTY Origin
6220-00-984-7767 2011-01-08 3 DIBBS
6220-00-984-7767 2007-09-244 1 DIBBS

Cross Reference | NSN 6220-00-984-7767

Part Number Cage Code Manufacturer
15-0030-1 72914 GRIMES AEROSPACE COMPANY DBA HONEYWELL

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 6220-00-984-7767

Technical Data | NSN 6220-00-984-7767

Characteristic Specifications
OVERALL HEIGHT 1.187 INCHES NOMINAL
OVERALL LENGTH 4.720 INCHES NOMINAL
OVERALL WIDTH 1.281 INCHES NOMINAL
VOLTAGE RATING IN VOLTS 28.0 DC NOMINAL
MATERIAL STEEL CORROSION RESISTING BODY GLASS LENS
SURFACE TREATMENT ENAMEL BAKED BODY
LAMP TYPE ACCOMMODATED AND QUANTITY 1 INCANDESCENT
LAMP BASE TYPE ACCOMMODATED MINIATURE BAYONET
LENS TYPE AND QUANTITY 1 TUBULAR
LENS SURFACE CONDITION SMOOTH BACK SMOOTH FACE
LENS COLOR COLORLESS AND RED
MOUNTING METHOD THREADED HOLE
TERMINAL TYPE AND QUANTITY 2 WIRE LEAD
WIRING PROVISION METHOD INDIVIDUAL WIRE
WIRING PROVISION LENGTH 74.0 INCHES NOMINAL ALL PROVISIONS
HAZARDOUS LOCATIONS/ENVIRONMENTAL PROTECTION ANY ACCEPTABLE
SPECIAL FEATURES ROTARY LENS
MANUFACTURERS CODE 72914
DESIGN CONTROL REFERENCE 15-0030-1

Restrictions/Controls & Freight Information | NSN 6220-00-984-7767

Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodePThere is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product
Demilitarization Code:QStrategic List Item (SLI). Demilitarization not required. SLI are non-MLI(Munitions List Items) controlled by the U.S. Dept. of Commerce through the Export Administration Regulations (EAR) and indicated on the Commerce Control List (CCL). Each CCL entry is preceded by a four-digit Export Control Commerce Control List Item (CCLI) – MUT to the point of scrap required outside the United States. Inside the United States, MUT is required when the DEMIL integrity code (IC) is “3” and MUT is not required when the DEMIL IC is “6.”
Controlled Inventory Item Code:UUNCLASSIFIED
Precious Metals Indicator Code:UPrecious metal type is unknown
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Category Code Description
NMF Description 109700 LAMP OR LIGHTING FIXTURES
Less than car load rating
Less than truck load rating W Rating Variable
Water commodity Code 658 unknown
Originating Activity Code XX
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity H Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc.
Air Special Handling Z No special handling required.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable

Management | NSN 6220-00-984-7767

Category Code Description
Budget Code9 General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors.
Price ValidationN The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
  • The price has not been analyzed or reviewed for accuracy.
  • ZOP or Standard price challenges are permissible, but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of ?L? or?F?,the case must be evaluated locally where purchased or fabricated.
Fund CodeSFStock fund applicable to items managed for the Air Force by the respective Inventory Control Point.
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDFDepartment of the Air Force
Service OrganizationFU.S. Air Force
ReparabilityNStock Fund (except Munitions)
Acquisition Advice CodesJNOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
Category Code Description
Cognizance Codes9BNavy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDNDepartment of the Navy
Service OrganizationNU.S. Navy
Acquisition Advice CodesJNOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
