NSN 6145-00-191-8404 AA59569, A-A-59569, AA59569F30T0375
Product Details | WIRE BRAID
6145-00-191-8404 An item formed by crossing three or more electrical conductors diagonally in such a manner that each conductor passes alternately over and under one or more of the others. Manufactured in flat or tubular shapes. Refers to bulk quantities only. See also SHIELD, SPARK PLUG.
Part Alternates: AA59569, A-A-59569, AA59569F30T0375, AA59569R30T0375, QQB575, QQ-B-575, QQB575R30T0375, QQB575R30T375, 087013103039, 087-013103-039, 6145-00-191-8404, 00-191-8404, 6145001918404, 001918404
Electric Wire, and Power and Distribution Equipment | Wire and Cable, Electrical
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 61 | 01 JAN 1963 | 00-191-8404 | 00386 ( BRAID, WIRE ) |
Drawings & Photos | NSN 6145-00-191-8404
Demand History | NSN 6145-00-191-8404
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| AA59569F30T0375 | 2021-01-07 | 25 | Israel |
| AA59569R30T0375 | 2021-01-07 | 0 | Israel |
| 6145-00-191-8404 | 2019-10-290 | 1250 | DIBBS |
| 6145-00-191-8404 | 2019-02-45 | 1250 | DIBBS |
| QQB575R30T375 | 2018-08-219 | 100 | ZA |
| QQB575R30T375 | 2018-08-219 | 500 | ZA |
| QQB575R30T375 | 2018-08-219 | 1000 | ZA |
| 6145-00-191-8404 | 2016-11-320 | 1300 | DIBBS |
| QQB575 | 2012-06-166 | 1 | US |
| 6145-00-191-8404 | 2011-04-100 | 3500 | DIBBS |
| 6145-00-191-8404 | 2011-01-18 | 1100 | DIBBS |
Cross Reference | NSN 6145-00-191-8404
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 087-013103-039 | 26916 | NORTHROP GRUMMAN SYSTEMS CORPORATION DIV MULTIPLE |
| A-A-59569 | 58536 | FEDERAL COMMERCIAL ITEM DESCRIPTION PROMULGATED BY GENERAL SERVICES |
| AA59569F30T0375 | 58536 | FEDERAL COMMERCIAL ITEM DESCRIPTION PROMULGATED BY GENERAL SERVICES |
| AA59569R30T0375 | 58536 | FEDERAL COMMERCIAL ITEM DESCRIPTION PROMULGATED BY GENERAL SERVICES |
| QQ-B-575 | 81348 | FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES |
| QQB575R30T0375 | 81348 | FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES |
| QQB575R30T375 | 81348 | FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 6145-00-191-8404
Related Products | NSN 6145-00-191-8404
Technical Data | NSN 6145-00-191-8404
| Characteristic | Specifications |
|---|---|
| CONDUCTOR FORM | BRAID, TUBULAR SINGLE CONDUCTOR |
| MATERIAL | COPPER CORE CONDUCTOR SINGLE CONDUCTOR |
| MATERIAL DOCUMENT AND CLASSIFICATION | ASTM B3 3 ASSN STD SINGLE MATERIAL RESPONSE CORE CONDUCTOR SINGLE CONDUCTOR |
| SURFACE TREATMENT | TIN CORE CONDUCTOR SINGLE CONDUCTOR |
| SURFACE TREATMENT DOCUMENT AND CLASSIFICATION | ASTM B33 ASSN STD SINGLE TREATMENT RESPONSE CORE CONDUCTOR SINGLE CONDUCTOR |
| ROUND CONDUCTOR SIZE | 8 AWG SINGLE CONDUCTOR |
| STRAND QUANTITY PER CONDUCTOR | 168 SINGLE CONDUCTOR |
| STRAND AWG SIZE PER CONDUCTOR | 30 SINGLE CONDUCTOR |
| CONDUCTOR CROSS-SECTIONAL SHAPE | TUBULAR BRAID SINGLE CONDUCTOR |
| INSIDE DIAMETER | 0.375 INCHES NOMINAL SINGLE CONDUCTOR |
| CROSS-SECTIONAL SHAPE STYLE | 6 ROUND |
| MANUFACTURERS CODE | 81348 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | QQ-B-575 |
| MANUFACTURERS CODE | 81348 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | QQB575R30T0375 |
Restrictions/Controls & Freight Information | NSN 6145-00-191-8404
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061130 | CABLE ASSEMBLY |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
