NSN 6115-01-306-7674 00906670, 01-306-7674, 013067674
Product Details | ALTERNATING CURRENT GENERATOR
6115-01-306-7674 A generator having a characteristic of current and voltage that is continually reversing in direction of flow at regular intervals. Does not include rotary inverters, motor-generators, generator sets, synchros, and frequency or phase changers. Excludes GENERATOR, TACHOMETER.
Part Alternates: 00906670, 6115-01-306-7674, 01-306-7674, 6115013067674, 013067674
Electric Wire, and Power and Distribution Equipment | Generators and Generator Sets, Electrical
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 61 | 30 AUG 1989 | 01-306-7674 | 00781 ( GENERATOR, ALTERNATING CURRENT ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 6115-01-306-7674
Related Products | NSN 6115-01-306-7674
Technical Data | NSN 6115-01-306-7674
| Characteristic | Specifications |
|---|---|
| MOUNTING METHOD | FLANGE |
| MOUNTING FACILITY TYPE AND QUANTITY | 8 UNTHREADED HOLE |
| MOUNTING FACILITY CIRCLE DIAMETER | 14.500 INCHES |
| INCLOSURE FEATURE | TOTALLY INCLOSED |
| CURRENT RATING IN AMPS | 2085.000 SINGLE INPUT |
| FREQUENCY IN HERTZ | 60.0 INPUT |
| PHASE | THREE INPUT |
| CONNECTION TYPE AND VOLTAGE RATING IN VOLTS | 450.0 LINE TO NEUTRAL SINGLE INPUT |
| POWER RATING | 1300.0 KILOWATTS OUTPUT |
| DUTY CYCLE | CONTINUOUS |
| TEMP RATING | 50.0 AMBIENT DEG CELSIUS |
| COOLING METHOD | WATER-AIR COOLED |
| ROTOR SPEED RATING IN RPM | 720.0 SINGLE FULL LOAD |
| SHAFT END CHARACTERISTIC | A25 SINGLE STYLE SINGLE END |
| SHAFT DIAMETER | 9.990 INCHES MINIMUM AND 10.000 INCHES MAXIMUM SINGLE END |
| COUPLING DIAMETER | 16.750 INCHES NOMINAL SINGLE END |
| COUPLING HOLE QUANTITY | 8 SINGLE END |
| MANUFACTURERS CODE | 00U45 |
| DESIGN CONTROL REFERENCE | 00906670 |
Restrictions/Controls & Freight Information | NSN 6115-01-306-7674
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 062120 | GENERATORS/MOTORS/PARTS NOI |
| Less than car load rating | W | Rating Variable |
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 590 | unknown |
| Originating Activity Code | HD | Naval Inventory Control Point Mechanicsburg, PA 17055-0788 |
| Air Dimension Code | Z | Shipment is not a consolidation, but does exceed 72 inches in one or more dimensions. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | R | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 6115-01-306-7674
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 7H | Depot level reparable shipboard and base equipment, assemblies, components and repair parts related to Naval Sea Systems Command equipment Naval Inventory Control Point, Mechanicsburg |
| Special Material Content | 9 | Non-Hazardous or Non-Sensitive Item, does not require hazardous or special handling, packaging or precautions |
| Source of Supply | NRP | NAVICP-ERP 700 Robbins Avenue Philadelphia, PA 19111-5098 |
| Agency | DN | Department of the Navy |
| Service Organization | L | Lead Service - 22 (Repairable) |
| Reparability | H | Depot Level Reparable |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
