NSN 6105-00-830-9857 11688892 , 11688901, 7174663
Product Details | DIRECT CURRENT MOTOR
6105-00-830-9857 A motor which is designed for operation from a direct current source. Excludes MOTOR, ENGINE STARTER, ELECTRICAL. See also MOTOR, CONTROL.
Part Alternates: 11688892 , 11688901, 7174663, 717466-3 , 7178011, 717801-1, 6105-00-830-9857, 00-830-9857, 6105008309857, 008309857
Electric Wire, and Power and Distribution Equipment | Motors, Electrical
Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
---|---|---|---|
61 | 06 SEP 1967 | 00-830-9857 | 16350 ( MOTOR, DIRECT CURRENT ) |
Request a Quote
What Our Customers Say
Compare
NSNs for Compare ( up to 4 ): Add 6105-00-830-9857
Related Products | NSN 6105-00-830-9857
Technical Data | NSN 6105-00-830-9857
Characteristic | Specifications |
---|---|
OVERALL LENGTH | 7.937 INCHES |
OVERALL WIDTH | 3.125 INCHES |
OVERALL HEIGHT | 3.125 INCHES |
LENGTH OF SHAFT FROM HOUSING | 1.447 INCHES FIRST END |
MOUNTING METHOD | FACE |
MOUNTING FACILITY TYPE AND QUANTITY | 4 THREADED HOLE |
MOUNTING FACILITY CIRCLE DIAMETER | 2.652 INCHES |
INCLOSURE FEATURE | TOTALLY INCLOSED |
INCLOSURE SPECIFICATION | MIL-STD-108 |
CURRENT RATING IN AMPS | 75.000 SINGLE INPUT |
CURRENT RATING METHOD | LOAD |
CONNECTION TYPE AND VOLTAGE RATING IN VOLTS | 24.0 LINE TO NEUTRAL SINGLE INPUT |
POWER RATING | 1.5000 HORSEPOWER OUTPUT |
TORQUE RATING AND TYPE | 11.2 INCH-POUNDS RUNNING |
WINDING TYPE | SERIES WOUND AND SHUNT WOUND |
DUTY CYCLE | INTERMITTENT |
TIME INTERVAL | 1.0 MINUTES MAXIMUM ON |
COOLING METHOD | NONVENTILATED |
MAXIMUM OPERATING ALTITUDE RATING | 10000.0 FEET |
TERMINAL TYPE AND QUANTITY | 2 CONNECTOR, PLUG |
SHAFT ROTATION DIRECTION | CLOCKWISE OR COUNTERCLOCKWISE SINGLE END |
ROTOR SPEED RATING IN RPM | 8500.0 SINGLE FULL LOAD |
SHAFT END CHARACTERISTIC | A2 FIRST STYLE AND A14 SECOND STYLE SINGLE END |
SHAFT DIAMETER | 0.4279 INCHES NOMINAL SINGLE END |
SPLINE LENGTH | 0.8750 INCHES NOMINAL SINGLE END |
SPLINE QUANTITY | 11 SINGLE END |
FEATURES PROVIDED | VERTICAL MOUNTING POSITION AND HORIZONTAL MOUNTING POSITION |
Restrictions/Controls & Freight Information | NSN 6105-00-830-9857
Category | Code | Description |
---|---|---|
Shelf-Life Code: | 0 | Nondeteriorative |
Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
Controlled Inventory Item Code: | U | UNCLASSIFIED |
Precious Metals Indicator Code: | A | Item does not contain precious metal |
Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
Category | Code | Description |
---|---|---|
NMF Description | 062120 | GENERATORS/MOTORS/PARTS NOI |
Less than car load rating | Q | 70 |
Less than truck load rating | W | Rating Variable |
Water commodity Code | 590 | unknown |
Originating Activity Code | BF | U.S. Army Armament and Chemical Acquisition and Logistics Activity Rock Island, IL 61299-6000 |
Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
Air Special Handling | Z | No special handling required. |
Special Handling Code | 9 | unknonwn |
HAZMAT | FF | |
Type of Cargo | Z | No special type of cargo code applicable |
NMF Description | 133300 | MACHINERY/MACHINES NOI |
Less than car load rating | M | 85 |
Less than truck load rating | W | Rating Variable |
Water commodity Code | 713 | unknown |
Originating Activity Code | BF | U.S. Army Armament and Chemical Acquisition and Logistics Activity Rock Island, IL 61299-6000 |
Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
Air Special Handling | Z | No special handling required. |
Special Handling Code | 9 | unknonwn |
HAZMAT | ||
Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 6105-00-830-9857
Category | Code | Description |
---|---|---|
Materiel Category and Inventory Manager | T | Industrial Supplies (DLA/GSA Items) |
Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
Specific Group/Generic Code | 0 | Medical Materiel |
Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
Agency | DA | Department of the Army |
Service Organization | A | U.S. Army |
Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
Controlled Item Code | U | UNCLASSIFIED |
Shelf Life Code | 0 | Nondeteriorative |
Purchasing | QTY UOM |
1 EA : Each |
Category | Code | Description |
---|---|---|
Cognizance Codes | 9H | Navy-owned stocks of consumable material managed by the Army within the Army Armament Materiel Readiness Command Naval Inventory Control Point, Mechanicsburg |
Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
Source of Supply | B14 | US Army Armament and Chemical Acquisition and Logistics Activity ATTN: AMSTA-AC Rock Island, IL 61299-6000 |
Agency | DN | Department of the Navy |
Service Organization | N | U.S. Navy |
Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
Controlled Item Code | U | UNCLASSIFIED |
Shelf Life Code | 0 | Nondeteriorative |
Purchasing | QTY UOM |
1 EA : Each |
Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
Agency | DN | Department of the Navy |
Service Organization | N | U.S. Navy |
Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
Controlled Item Code | U | UNCLASSIFIED |
Shelf Life Code | 0 | Nondeteriorative |
Purchasing | QTY UOM |
1 EA : Each |
