NSN 6105-00-014-6790 AWRH-8-DD-0003T9/C434, AWRH8DD0003T9C434, 621402
Product Details | MOTOR-TACHOMETER GENERATOR
6105-00-014-6790 An item which is an electrical rotating machine combining both control motor and tachometer generator action. The control motor and tachometer generator may be contained in the same or separate housings. It is designed for servo application where instant response to input signal is essential. It is generally used in circuits where the output potential from the tachometer generator is fed back to prevent excessive oscillation and for assuring high stability in a servo loop. Excludes DYNAMOTOR; and MOTOR-GENERATOR.
Part Alternates: AWRH-8-DD-0003T9/C434, AWRH8DD0003T9C434, 621402, 6214-02, 9300830005, 930-083-0005, 6105-00-014-6790, 00-014-6790, 6105000146790, 000146790
Electric Wire, and Power and Distribution Equipment | Motors, Electrical
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 61 | 15 MAY 1968 | 00-014-6790 | 28454 ( MOTOR-TACHOMETER GENERATOR ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 6105-00-014-6790
Technical Data | NSN 6105-00-014-6790
| Characteristic | Specifications |
|---|---|
| OVERALL LENGTH | 1.615 INCHES |
| OVERALL WIDTH | 0.750 INCHES |
| LENGTH OF SHAFT FROM HOUSING | 0.335 INCHES SINGLE END |
| MOUNTING METHOD | CLAMP RING |
| MOUNTING FACILITY TYPE AND QUANTITY | 1 CLAMP COLLAR |
| INCLOSURE FEATURE | TOTALLY INCLOSED |
| INCLOSURE SPECIFICATION | COMMERCIAL |
| CURRENT TYPE | AC INPUT |
| FREQUENCY IN HERTZ | 400.0 OUTPUT |
| PHASE | SINGLE INPUT |
| CONNECTION TYPE AND VOLTAGE RATING IN VOLTS | 26.0 LINE TO NEUTRAL SINGLE INPUT |
| POWER RATING | 5.370 WATTS INPUT |
| TORQUE RATING AND TYPE | 0.2 INCH-OUNCES STALLED |
| EXCITOR TYPE | SEPARATELY EXCITED |
| TEMP RATING | -55.0 OPERATING DEG CELSIUS AND 125.0 OPERATING DEG CELSIUS |
| COOLING METHOD | NONVENTILATED |
| TERMINAL TYPE AND QUANTITY | 9 WIRE LEAD |
| CALIBRATION VOLTAGE OUTPUT TYPE IN VOLTS | 330.0 AC |
| CALIBRATION SPEED IN RPM | 1000.0 |
| CONTROL FIELD VOLTAGE TYPE AND RATING IN VOLTS | 20.0 AC AND 40.0 AC |
| ROTOR SPEED RATING IN RPM | 6200.0 SINGLE NO LOAD |
| SHAFT END CHARACTERISTIC | A14 SINGLE STYLE SINGLE END |
| SPLINE MINOR DIAMETER | 0.1083 INCHES NOMINAL SINGLE END |
| SHAFT DIAMETER | 0.1237 INCHES MINIMUM AND 0.1247 INCHES MAXIMUM SINGLE END |
| SPLINE LENGTH | 0.2900 INCHES NOMINAL SINGLE END |
| SPLINE QUANTITY | 13 SINGLE END |
| FEATURES PROVIDED | VERTICAL MOUNTING POSITION AND HORIZONTAL MOUNTING POSITION |
Restrictions/Controls & Freight Information | NSN 6105-00-014-6790
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 062120 | GENERATORS/MOTORS/PARTS NOI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 593 | unknown |
| Originating Activity Code | AX | Defense Supply Center Columbus Columbus, OH 43216-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
