NSN 5999-01-357-7030 CPG1027/1-032, CPG10271032, 063G0252
Product Details | ELECTRONIC SHIELDING GASKET
5999-01-357-7030 A shaped metallic item designed to increase the effectiveness of radio frequency/electromagnetic interference, or a nonmetallic item containing a wire mesh, metal, or other electrically conductive particles designed to provide environmental sealing and radio frequency/electromagnetic interference shielding. For bulk items see WIRE MESH, KNITTED or GASKETING MATERIAL, CONDUCTIVE.
Part Alternates: CPG1027/1-032, CPG10271032, 063G0252, 06-3G-0252, 5999-01-357-7030, 01-357-7030, 5999013577030, 013577030
Electrical and Electronic Equipment Components | Miscellaneous Electrical and Electronic Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 30 APR 1992 | 01-357-7030 | 20281 ( SHIELDING GASKET, ELECTRONIC ) |
Drawings & Photos | NSN 5999-01-357-7030
Demand History | NSN 5999-01-357-7030
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| CPG1027-1-032 | 2022-10-279 | 31 | DIBBS |
| CPG1027-1-032 | 2021-05-129 | 10 | DIBBS |
| CPG1027-1-032 | 2021-01-07 | 41 | DIBBS |
| 5999-01-357-7030 | 2018-04-105 | 58 | DIBBS |
| 5999-01-357-7030 | 2011-12-353 | 20 | US |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5999-01-357-7030
Technical Data | NSN 5999-01-357-7030
| Characteristic | Specifications |
|---|---|
| CROSS-SECTIONAL SHAPE STYLE | F79 MESH AND COMPOSITION |
| CROSS-SECTIONAL HEIGHT | 0.065 INCHES MINIMUM AND 0.075 INCHES MAXIMUM |
| STYLE DESIGNATOR | B36C CIRCULAR WITH SLOTS |
| SLOT WIDTH | 0.120 INCHES MINIMUM AND 0.135 INCHES MAXIMUM |
| OUTSIDE DIAMETER | 3.325 INCHES MINIMUM AND 3.345 INCHES MAXIMUM |
| APERTURE DIAMETER | 1.635 INCHES MINIMUM AND 1.645 INCHES MAXIMUM |
| SLOT RADIUS | 0.015 INCHES NOMINAL |
| SLOT QUANTITY | 1 |
Restrictions/Controls & Freight Information | NSN 5999-01-357-7030
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 062800 | RADIO/TV RECEIVING SET CHASSIS ETC |
| Less than car load rating | ||
| Less than truck load rating | M | 85.0 |
| Water commodity Code | 723 | unknown |
| Originating Activity Code | TX | Defense Supply Center Columbus Columbus, OH 43218 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5999-01-357-7030
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
