Product Details | DELAY LINE
5999-01-005-9484 An item which provides a predetermined delay to an electrical pulse, while maintaining substantially the same waveform. The delay is obtained by means of a real or artificial transmission line or equivalent device. The equivalent device may be acoustic, distributive, lumped constant, magnetic solid state, or surface acoustical wave type. See also ATTENUATOR, (as modified); TRANSFORMER, (as modified); and OSCILLATOR, PULSE DELAY.
Part Alternates: 15168801, 151688-01, 1683, 5999-01-005-9484, 01-005-9484, 5999010059484, 010059484
Electrical and Electronic Equipment Components | Miscellaneous Electrical and Electronic Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 13 JUL 1975 | 01-005-9484 | 06373 ( DELAY LINE ) |
Drawings & Photos | NSN 5999-01-005-9484
Demand History | NSN 5999-01-005-9484
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 1683 | 2019-04-92 | 1 | United States |
| 1683 | 2014-07-203 | 2 | US |
| 1683 | 2012-09-254 | 4 | AR |
| 1683 | 2011-12-347 | 50 | Canada |
| 1683 | 2011-08-230 | 25 | US |
| 1683 | 2011-06-180 | 40 | France |
| 1683 | 2011-01-24 | 1 | US |
| 1683 | 2010-03-83 | 1 | US |
| 1683 | 2009-06-180 | 20 | US |
| 1683 | 2006-04-118 | 10 | us |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5999-01-005-9484
Related Products | NSN 5999-01-005-9484
Technical Data | NSN 5999-01-005-9484
| Characteristic | Specifications |
|---|---|
| SIGNAL DELAY METHOD | LUMPED CONSTANT |
| DELAY TIME VARIATION METHOD | TAPPED |
| INDIVIDUAL SECTION QUANTITY | 1 |
| OPERATING TEMP RANGE | NOT RATED |
| DELAY TIME VARIATION PER DEG CELSIUS | NOT RATED |
| INPUT IMPEDANCE RATING | NOT RATED |
| OUTPUT IMPEDANCE RATING | NOT RATED |
| ATTENUATION IN DECIBELS | NOT RATED |
| VOLTAGE RATING | NOT RATED |
| PULSE RISE TIME RATING | NOT RATED |
| FREQUENCY RATING | NOT RATED |
| FREQUENCY BANDWIDTH | NOT RATED |
| BODY STYLE | 1 RECTANGULAR |
| BODY LENGTH | 0.620 INCHES MAXIMUM |
| BODY WIDTH | 0.620 INCHES MAXIMUM |
| BODY DEPTH | 0.340 INCHES MAXIMUM |
| TERMINAL TYPE AND QUANTITY | 16 PIN |
| MOUNTING FACILITY | PIN |
| MOUNTING FACILITY QUANTITY | 16 |
| MOUNTING PROVISION ARRANGEMENT STYLE | 2 FOUR POSITION RECTANGULAR |
| LONGEST HORIZONTAL DISTANCE BETWEEN MOUNTING CENTERS | 0.400 INCHES NOMINAL |
| LONGEST VERTICAL DISTANCE BETWEEN MOUNTING CENTERS | 0.400 INCHES NOMINAL |
| III PRECIOUS MATERIAL | GOLD |
| III PRECIOUS MATERIAL AND LOCATION | PIN SURFACE GOLD |
