NSN 5998-01-185-0882 011850882
Product Details | ELECTRONIC COMPONENTS ASSEMBLY
5998-01-185-0882 A grouping of two or more different types of electrical/electronic components mounted on a common mounting. It may include an assembly of electrical/electronic components mounted on multiple PRINTED WIRING BOARD(S) mounted back to back, stacked, and the like. The item is generally a component of a subassembly and cannot be assigned a more definite item name. Excludes items which may be identified as a subassembly. For an assembly of electrical/electronic components mounted on a single PRINTED WIRING BOARD, see CIRCUIT CARD ASSEEMBLY. Do not use if a more specific name applies.
Part Alternates: 011850882
Electrical and Electronic Equipment Components | Electrical and Electronic assemblies, Boards, Cards, and Associated Hardware
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 25 JUL 1984 | 01-185-0882 | 26088 ( ELECTRONIC COMPONENTS ASSEMBLY ) |
Cross Reference | NSN 5998-01-185-0882
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 100408-1 | 51644 | WEST TECH SYSTEMS INC DBA WESTERN TECHNICAL ASSOCIATES |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5998-01-185-0882
Technical Data | NSN 5998-01-185-0882
| Characteristic | Specifications |
|---|---|
| OVERALL HEIGHT | 3.000 INCHES NOMINAL |
| END ITEM IDENTIFICATION | MALSR,HV REIL AND REIL FLASHING LIGHT SYSTEMS,FA-9987 SEQUENCED FLASHING LIGHT TYPE III,DTFA-01-80-C-20051,TI6850.54 |
| SPECIAL FEATURES | CAPACITOR 60,DIODE 11,MICRO-CIRCUIT 16,PRINTED WIRING BOARD 2,RELAY 1,RESISTOR 42,TRANSFORMER 1,TRANSISTOR 7,VOLTAGE REGULATOR 2 |
| OVERALL WIDTH | 13.000 INCHES NOMINAL |
| OVERALL LENGTH | 15.000 INCHES NOMINAL |
Restrictions/Controls & Freight Information | NSN 5998-01-185-0882
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
