NSN 5985-01-452-0695 635195-004, 01-452-0695, 635195004
Product Details | ANTENNA
5985-01-452-0695 An item consisting of a conductor or a system of conductors specifically designed to radiate and/or receive electromagnetic waves in free space. May include beam-forming devices, drive motors, synchros, radome, and associated mechanical structure.
Part Alternates: 635195-004, 5985-01-452-0695, 01-452-0695, 5985014520695, 635195004, 014520695
Electrical and Electronic Equipment Components | Antennas, Waveguides, and Related Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 14 JAN 1998 | 01-452-0695 | 00749 ( ANTENNA ) |
Demand History | NSN 5985-01-452-0695
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 635195004 | 2014-03-88 | 1 | US |
Cross Reference | NSN 5985-01-452-0695
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 635195-004 | 62065 | EDO RECONNAISSANCE AND SURVEILLANCE SYSTEMS, INC. |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5985-01-452-0695
Technical Data | NSN 5985-01-452-0695
| Characteristic | Specifications |
|---|---|
| ELECTROMAGNETIC POLARIZATION TYPE | SLANT LINEAR SINGLE ANTENNA ELEMENT |
| RADIATION PATTERN | OMNIDIRECTIONAL SINGLE ANTENNA ELEMENT |
Restrictions/Controls & Freight Information | NSN 5985-01-452-0695
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | D | Munitions List Item or Commerce Control List Item. Demilitarization required. Total destruction of the item and components so as to preclude restoration or repair to a usable condition by melting, cutting, tearing, scratching, crushing, breaking, punching, neutralizing, etc. (As an alternate, burial or deep water dumping may be used when coordinated with the DoD Demilitarization Program Office.) |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
