Product Details | WAVEGUIDE
5985-01-180-6731 An item consisting of a hollow tube of conductive material having a predetermined cross section specifically designed to guide or conduct high frequency electromagnetic energy through its interior. Does not include coaxial cable. Refers to bulk quantities only.
Part Alternates: 403832, 5985-01-180-6731, 01-180-6731, 5985011806731, 011806731
Electrical and Electronic Equipment Components | Antennas, Waveguides, and Related Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 31 MAY 1984 | 01-180-6731 | 00510 ( WAVEGUIDE ) |
Drawings & Photos | NSN 5985-01-180-6731
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5985-01-180-6731
Technical Data | NSN 5985-01-180-6731
| Characteristic | Specifications |
|---|---|
| STYLE DESIGNATOR | B1 STRAIGHT TYPE |
| WAVEGUIDE LENGTH | 4.740 FEET MINIMUM AND 4.743 FEET MAXIMUM |
| CROSS-SECTIONAL SHAPE STYLE | A1 INTERNAL, RECTANGULAR EXTERNAL, RECTANGULAR |
| WAVEGUIDE OUTSIDE WIDTH | 0.910 INCHES MINIMUM AND 0.914 INCHES MAXIMUM |
| WAVEGUIDE INSIDE WIDTH | 0.770 INCHES MINIMUM AND 0.778 INCHES MAXIMUM |
| WAVEGUIDE INSIDE HEIGHT | 0.194 INCHES MINIMUM AND 0.196 INCHES MAXIMUM |
| WAVEGUIDE OUTSIDE HEIGHT | 0.326 INCHES MINIMUM AND 0.330 INCHES MAXIMUM |
| FLEXIBILITY | RIGID SINGLE TUBING SEGMENT |
| TUBING WALL CONSTRUCTION STYLE | J1 SEAMLESS SINGLE TUBING SEGMENT |
| MATERIAL | ALUMINUM ALLOY THIRD TUBING SEGMENT |
