Product Details | WAVEGUIDE SEAL
5985-00-876-4051 An item or assembly designed to be fitted into or external to the end of a waveguide, in order to prevent the entrance of moisture or other foreign matter, without appreciably attenuating radio frequencies. May or may not be pressure proof.
Part Alternates: SRCCA13923, SRC-CA1392-3, 678786, 9176372, 5985-00-876-4051, 00-876-4051, 5985008764051, 008764051
Electrical and Electronic Equipment Components | Antennas, Waveguides, and Related Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1962 | 00-876-4051 | 02477 ( SEAL, WAVEGUIDE ) |
Drawings & Photos | NSN 5985-00-876-4051
