NSN 5985-00-876-4569 N20884431, N2088443-1, D408431
Product Details | RADIO FREQUENCY ROTARY COUPLER
5985-00-876-4569 An item which provides a means of transfer of electrical energy between two components or sets, and which is specifically designed to permit one section of a transmission line or waveguide to rotate continuously with respect to another, and still maintain radio frequency continuity.
Part Alternates: N20884431, N2088443-1, D408431, 20884431, 2088443-1, 5985-00-876-4569, 00-876-4569, 5985008764569, 008764569
Electrical and Electronic Equipment Components | Antennas, Waveguides, and Related Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 17 NOV 1967 | 00-876-4569 | 00371 ( COUPLER, ROTARY, RADIO FREQUENCY ) |
Cross Reference | NSN 5985-00-876-4569
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 2088443-1 | 06845 | RAYTHEON COMPANY DBA RAYTHEON |
| 2088443-1 | 27914 | HONEYWELL INTERNATIONAL INC DBA HONEYWELL |
| D408431 | 25634 | KEVLIN CORPORATION DBA COBHAM SENSOR SYSTEMS |
| D408431 | 66544 | CONTINENTAL MICROWAVE AND TOOL CO., INC. |
| D408431 | 80006 | LITTON SYSTEMS INC AIRTRON DIV |
| N2088443-1 | 94931 | BENDIX CORP THE BENDIX INTERNATIONAL DIV |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5985-00-876-4569
Technical Data | NSN 5985-00-876-4569
| Characteristic | Specifications |
|---|---|
| UNIT TYPE | WAVEGUIDE |
| RADIO FREQUENCY RATING | 9.345 GIGAHERTZ MINIMUM AND 9.405 GIGAHERTZ MAXIMUM |
| MATERIAL | ALUMINUM ALLOY |
| OVERALL LENGTH | 4.594 INCHES NOMINAL |
| OVERALL DIAMETER | 1.374 INCHES NOMINAL |
| MOUNTING CONFIGURATION | 8 MTG HOLES 0.164 IN. DIA IRREGULARLY SPACED |
| III FSC APPLICATION DATA | WEATHER RADAR SET |
| MANUFACTURERS CODE | 25634 |
| DESIGN CONTROL REFERENCE | D408431 |
Restrictions/Controls & Freight Information | NSN 5985-00-876-4569
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | B | Munitions List Item - Mutilation (MUT) to the point of scrap required. (Formerly: Demilitarization not required. Trade Security Controls (TSCs) required at disposition.) |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 063520 | WAVEGUIDE IN BOXES/CRATES SUB |
| Less than car load rating | J | 100.2 |
| Less than truck load rating | M | 85.0 |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | SX | Oklahoma City Air Logistics Center Tinker AFB, OK 73145-3043 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | Z | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
