Product Details | ELECTRICAL DUMMY LOAD

5985-00-818-4627 A specific electrical element or set of electrical elements that are connected together to form a fixed arrangement and used as a substitute load for terminating an electrical circuit. A dummy load contains all the essential electrical characteristics necessary to terminate the circuit but does not function in the same manner as the load which it replaces. Examples are resistors used to replace antennas, batteries, loudspeakers, or the like. Includes single port terminations of twin lead, coaxial and waveguide transmission lines as low power terminations of a section of a transmission system in a specified manner. Includes dummy loads when arranged in a group or bank. Excludes power absorbers. See also LOAD BANK, ELECTRICAL.

Part Alternates: MS28775136, MS28775-136 , N30475136, N304-75-136 , ARP568-MILP2573 2 , ARP568MILP25732, AS28775, SP100124, SP100-124 , SR 832-75-136 , SR83275136, DA218U, JKN00163260, MILP25732, MIL-P-25732 , P48026136, P48026-136 , PRP568136406770, PRP568-136-4067-70 , 522-1741-00, 5221741000, 522-1741-000, 522174100REVM, 522-1741-00REVM, 04050452035637 , 0716768, 1243003247, 124-3003-247 , 1446136, 1446-136 , 1551258169, 1551258-169 , 1639817PC169 , 199991, 2-136 N304-75 , 2136N30475, 2300-79066 , 28775136, 28775-136 , 2HHA103PC16 , 4067-70-136 , 7377136, 7377-136 , 5985-00-818-4627, 00-818-4627, 5985008184627, 008184627, 522174100, 406770136, 230079066

Electrical and Electronic Equipment Components | Antennas, Waveguides, and Related Equipment

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
59	01 JAN 1962	00-818-4627	00335 ( DUMMY LOAD, ELECTRICAL )

Drawings & Photos | NSN 5985-00-818-4627

Part Number	Request Date	QTY	Origin
MILP25732	2023-09-261	15	US
MILP25732	2023-09-261	15	US
199991	2021-05-132	2	United States
MS28775136	2019-07-183	8	United States
199991	2018-02-52	1	United States
MS28775136	2017-03-79	10	United States
MS28775136	2017-02-37	25	Egypt
2-136 N304-75	2016-03-81	27	United States
MS28775-136	2015-03-76	40	TH
MS28775-136	2015-03-76	10	TH
MS28775136	2014-10-294	3	ZA
MS28775136	2014-02-38	1	us
MS28775136	2013-07-205	5	Singapore
MS28775-136	2013-01-07	10	Indonesia
MS28775136	2011-08-237	10	United States

Cross Reference | NSN 5985-00-818-4627

Part Number	Cage Code	Manufacturer
522-1741-00	05584	AUTODYNE MANUFACTURING CO., INC.
522-1741-00	95692	EDO ARTISAN INC
522-1741-000	13499	ROCKWELL COLLINS, INC. DBA GOVERNMENT SYSTEMS
522-1741-00REVM	13499	ROCKWELL COLLINS, INC. DBA GOVERNMENT SYSTEMS
DA218U	80058	JOINT ELECTRONICS TYPE DESIGNATION SYSTEM

Request a Quote

What Our Customers Say

Thank you very much for the excellent service and professional customer care.

Ernie G. Honeywell

The service was excellent. I can think of no improvements to date that you can make regarding internet sales.

John L. Raytheon

The representative for WBParts was efficient & handled our request in a timely & professional manner.

Karen G. General Dynamics

Tried two other sources, neither of them responded, was all done online, never spoke to anyone.

Rex S. US Airforce

The response is quick and the price is often very good. We are completely satisfied.

Patricia S. NASA

Compare

NSNs for Compare ( up to 4 ): Add 5985-00-818-4627

Compare

Related Products | NSN 5985-00-818-4627

5985-00-818-4843, 5985-00-818-5483, 5985-00-818-5484, 5985-00-818-5486, 5985-00-818-5487

Technical Data | NSN 5985-00-818-4627

Characteristic	Specifications
STYLE DESIGNATOR	18A WAVEGUIDE MOUNTED
OVERALL LENGTH	20.875 INCHES NOMINAL
OVERALL HEIGHT	2.687 INCHES NOMINAL
OVERALL WIDTH	2.875 INCHES NOMINAL
FREQUENCY RANGE RATING	2.000 TO 3.000 MEGAHERTZ
POWER RATING	500.000 WATTS AVERAGE
IMPEDANCE RATING IN OHMS	50.0 NOMINAL
VOLTAGE STANDING WAVE RATIO	1.30
TERMINATION TYPE	CONNECTION COAXIAL
COAXIAL CONNECTOR SERIES DESIGNATION	BNC
CONNECTOR END DESIGN	FEMALE
COOLING METHOD	SELF-COOLED
OPERATING POSITION	VERTICAL
III FSC APPLICATION DATA	RADIO SET,RADIO,EXCEPT NAVIGATION,NONAIRBORNE
