NSN 5985-00-519-9886 AS-390A/SRC, AS390ASRC, RE66D585
Product Details | ANTENNA
5985-00-519-9886 An item consisting of a conductor or a system of conductors specifically designed to radiate and/or receive electromagnetic waves in free space. May include beam-forming devices, drive motors, synchros, radome, and associated mechanical structure.
Part Alternates: AS-390A/SRC, AS390ASRC, RE66D585, RE66D585H, RE66F585C, RED2691804, RE-D2691804, 5985-00-519-9886, 00-519-9886, 5985005199886, 005199886
