Product Details | ELECTRICAL INSULATION SLEEVING

5970-01-628-9585 A rigid or flexible tubing having uniform inside and outside diameters in the overall length. It is specifically designed to prevent any undesirable flow of current between conductors and other objects. Includes shrinkable type tubing, items in bulk and in specific fabricated lengths (cut to size). Excludes items not having rated electrical characteristics. Also excludes BUSHING, SLEEVE; CABLE NIPPLE, ELECTRICAL; CONDUIT (as modified); INSULATION SLEEVING, ELECTRICAL, SPECIAL PURPOSE; INSULATION SLEEVING, THERMAL; SLEEVE, MARKER, CABLE; SLEEVING, TEXTILE, ELECTRICAL; TUBING, GLASS; and TUBING, NONMETALLIC.

Part Alternates: M23053/5-109-0 , M2305351090, 5970-01-628-9585, 01-628-9585, 5970016289585, 016289585

Electrical and Electronic Equipment Components | Electrical Insulators and Insulating Materials

Supply Group (FSG) NSN Assign. NIIN
59 2014167 01-628-9585

Drawings & Photos | NSN 5970-01-628-9585


Demand History | NSN 5970-01-628-9585

Part Number Request Date QTY Origin
M23053/5-109-0 2023-09-253 2795 DIBBS
M23053/5-109-0 2020-12-355 1471 DIBBS
M2305351090 2020-12-344 1 United States
M2305351090 2020-12-344 1 United States
M2305351090 2020-07-195 16 US
M2305351090 2020-01-09 1 US
5970-01-628-9585 2017-08-220 878 DIBBS
M2305351090 2017-07-208 10 Colombia
5970-01-628-9585 2016-06-167 655 DIBBS
M2305351090 2016-06-166 24 US
5970-01-628-9585 2016-06-159 655 DIBBS
5970-01-628-9585 2016-03-78 53 DIBBS
5970-01-628-9585 2016-03-70 53 DIBBS
M2305351090 2016-02-49 2 United States
5970-01-628-9585 2014-12-345 17 DIBBS
5970-01-628-9585 2014-12-337 17 DIBBS
5970-01-628-9585 2014-07-198 29 DIBBS
5970-01-628-9585 2014-07-190 29 DIBBS
M2305351090 2013-12-345 12 United States
M2305351090 2011-03-69 25 US
M2305351090 2007-06-165 20 US

Cross Reference | NSN 5970-01-628-9585

Part Number Cage Code Manufacturer
M23053/5-109-0 6A2X5 HEAT SHRINK SUPPLY

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 5970-01-628-9585

Technical Data | NSN 5970-01-628-9585

Characteristic Specifications
STYLE DESIGNATOR SHRINKABLE
WALL THICKNESS 0.030 INCHES NOMINAL
EXPANDED INSIDE DIAMETER 0.750 INCHES NOMINAL
RECOVERED INSIDE DIAMETER 0.030 INCHES NOMINAL
COATING MATERIAL PLASTIC, POLYOLEFIN
DESIGN FORM FULL ROUND
RELIABILITY INDICATOR NOT ESTABLISHED
III END ITEM IDENTIFICATION CONSOL GSE
III PART NAME ASSIGNED BY CONTROLLING AGENCY INSULATION SLEEVING, ELECTRICAL, HEAT SHRINKABLE

Restrictions/Controls & Freight Information | NSN 5970-01-628-9585

Category Code Description
Hazardous Material Indicator CodePThere is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
NMF Description 103300 INSULATING MATERIAL NOI
Less than car load rating
Less than truck load rating W Rating Variable
Water commodity Code 72D unknown
Originating Activity Code KE Naval ICP
Philadelphia, PA 19111
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity H Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc.
Air Special Handling Z No special handling required.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable

Management | NSN 5970-01-628-9585

Category Code Description
Cognizance Codes9BNavy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDNDepartment of the Navy
Service OrganizationNU.S. Navy
Acquisition Advice CodesZINSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
T
FT : Foot
