Product Details | ELECTRICAL INSULATION SHEET

5970-01-499-4908 A material whose thickness is small in comparison to its length and width, and which is specifically designed to prevent any undesirable flow of current between a conductor(s) and/or other objects. Excludes items which do not have definite rated electrical characteristics. Excludes INSULATION CLOTH, ELECTRICAL; INSULATION TAPE, ELECTRICAL and PLASTIC SHEET. For electrical insulation sheets fabricated for a specific application, see INSULATOR (as modified).

Part Alternates: M24768/27-S-14, M2476827S14, MIL-I-24768/27, MILI2476827, 5970-01-499-4908, 01-499-4908, 5970014994908, 014994908

Electrical and Electronic Equipment Components | Electrical Insulators and Insulating Materials

Supply Group (FSG) NSN Assign. NIIN
59 24 JUL 2002 01-499-4908

Cross Reference | NSN 5970-01-499-4908

Part Number Cage Code Manufacturer
M24768/27-S-14 81349 MILITARY SPECIFICATIONS PROMULGATED BY MILITARY
MIL-I-24768/27 81349 MILITARY SPECIFICATIONS PROMULGATED BY MILITARY

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 5970-01-499-4908

Technical Data | NSN 5970-01-499-4908

Characteristic Specifications
MATERIAL PLASTIC, EPOXY RESIN AND GLASS EPOXY, LAMINATED
DIELECTRIC WITHSTANDING VOLTAGE RATING 45.0 VOLTS
ADHESIVE NOT PROVIDED
THICKNESS 0.312 INCHES NOMINAL
SPECIAL FEATURES LAMINATED THERMOSETTING, GLASS-CLOTH EPOXY-RESIN GEE-F MATERIAL
MANUFACTURERS CODE 81349
NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE MIL-I-24768/27
MANUFACTURERS CODE 81349
DEFINITIVE GOVERNMENT SPEC/STD REFERENCE M24768/27-S-14

Restrictions/Controls & Freight Information | NSN 5970-01-499-4908

Category Code Description
Hazardous Material Indicator CodePThere is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Electro-static Discharge Susceptible:ANo known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
No Freight Information
