NSN 5970-01-014-3906 MILI24204, MIL-I-24204, 414
Product Details | ELECTRICAL INSULATION SHEET
5970-01-014-3906 A material whose thickness is small in comparison to its length and width, and which is specifically designed to prevent any undesirable flow of current between a conductor(s) and/or other objects. Excludes items which do not have definite rated electrical characteristics. Excludes INSULATION CLOTH, ELECTRICAL; INSULATION TAPE, ELECTRICAL and PLASTIC SHEET. For electrical insulation sheets fabricated for a specific application, see INSULATOR (as modified).
Part Alternates: MILI24204, MIL-I-24204, 414, 5970-01-014-3906, 01-014-3906, 5970010143906, 010143906
Electrical and Electronic Equipment Components | Electrical Insulators and Insulating Materials
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 23 DEC 1975 | 01-014-3906 | 00789 ( INSULATION SHEET, ELECTRICAL ) |
Drawings & Photos | NSN 5970-01-014-3906
Demand History | NSN 5970-01-014-3906
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 414 | 2015-05-134 | 2 | |
| 414 | 2014-07-197 | 1 | |
| 414 | 2010-04-96 | 10 | United States |
| 414 | 2010-03-90 | 10 | United States |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5970-01-014-3906
Technical Data | NSN 5970-01-014-3906
| Characteristic | Specifications |
|---|---|
| MATERIAL | PAPER,FIBER,MIL-I-24204,TYPE II,FORM S |
| DIELECTRIC WITHSTANDING VOLTAGE RATING | NOT RATED |
| DIELECTRIC MATERIAL VOLTAGE RATING PER MIL THICKNESS IN VOLTS | 650.0 |
| IDENTIFICATION CODE COLOR | NATURAL |
| ADHESIVE | NOT PROVIDED |
| WIDTH | 36.000 INCHES NOMINAL |
| LENGTH | 50.000 FEET NOMINAL |
| THICKNESS | 0.015 INCHES NOMINAL |
| UNIT PACKAGE QUANTITY | 1 |
| UNIT PACKAGE TYPE | ROLL |
| NONDEFINITIVE SPEC/STD DATA | II TYPE AND S FORM |
| MANUFACTURERS CODE | 81349 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MIL-I-24204 |
