Product Details | ELECTRICAL INSULATION SHEET
5970-00-905-8758 A material whose thickness is small in comparison to its length and width, and which is specifically designed to prevent any undesirable flow of current between a conductor(s) and/or other objects. Excludes items which do not have definite rated electrical characteristics. Excludes INSULATION CLOTH, ELECTRICAL; INSULATION TAPE, ELECTRICAL and PLASTIC SHEET. For electrical insulation sheets fabricated for a specific application, see INSULATOR (as modified).
