NSN 5965-00-284-6718 H-39/A, H-39A/U, H39AU
Product Details | ELECTRICAL HEADSET
5965-00-284-6718 An item consisting of one or two earphones with a connecting cord and with or without a headband. Single headphone type must include facilities as required for use. For items without earphones designed to protect the ears from noise, see PROTECTOR, HEARING.
Part Alternates: H-39/A, H-39A/U, H39AU, RE51F129PC13, H39A, 0180163407, 01801-63407, 10265B, 200122, 20012-2, 5965-00-284-6718, 00-284-6718, 5965002846718, 002846718
Electrical and Electronic Equipment Components | Headsets, Handsets, Microphones and Speakers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1963 | 00-284-6718 | 00737 ( HEADSET, ELECTRICAL ) |
Drawings & Photos | NSN 5965-00-284-6718
Demand History | NSN 5965-00-284-6718
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| H39A | 2019-03-06 | 6 | United States |
Cross Reference | NSN 5965-00-284-6718
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 01801-63407 | 28480 | HEWLETT-PACKARD COMPANY DBA HEWLETT-PACKARD CO. OR HP |
| 10265B | 18068 | ASTROCOM ELECTRONICS, INC. |
| 20012-2 | 78711 | TELEPHONICS CORPORATION DBA COMMUNICATIONS SYSTEMS DIVISION |
| H-39/A | 06442 | CANBERRA INDUSTRIES, INC. |
| H-39/A | 18068 | ASTROCOM ELECTRONICS, INC. |
| H-39/A | 56875 | M & S ELECTRONICS INC |
| H-39A/U | 80058 | JOINT ELECTRONICS TYPE DESIGNATION SYSTEM |
| RE51F129PC13 | 80064 | NAVAL SHIP SYSTEMS COMMAND |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5965-00-284-6718
Related Products | NSN 5965-00-284-6718
Technical Data | NSN 5965-00-284-6718
| Characteristic | Specifications |
|---|---|
| HEADBAND TYPE | ADJUSTABLE DOUBLE BAND |
| HEADBAND MATERIAL | METAL |
| HEADBAND COVERING MATERIAL | RUBBER |
| HEADSET CORD LENGTH | 60.0 INCHES NOMINAL |
| EARPHONE ELEMENT TYPE | MAGNETIC |
| CHANNEL MONITOR CAPABILITY | SINGLE CHANNEL |
| EARPHONE QUANTITY | 2 |
| EARPHONE CAP MATERIAL | ANY ACCEPTABLE |
| EARPHONE SHELL MATERIAL | ANY ACCEPTABLE |
| EARPHONE CUSHION MATERIAL | ANY ACCEPTABLE |
| EARPHONE INTERCONNECTION ARRANGEMENT | SERIES |
| TERMINAL TYPE | WIRE LEAD |
| TERMINAL QUANTITY | 1 |
| TERMINAL LOCATION | EXTERNAL |
| EARPHONE MOUNTING METHOD | DIAMETRICALLY OPPOSED HOLES IN OUTSIDE PERIPHERY OF CASE |
| BODY STYLE | 8 HEADSET, COVERED |
| HEADSET OVERALL HEIGHT | 6.125 INCHES NOMINAL |
| HEADSET OVERALL WIDTH | 6.500 INCHES NOMINAL |
| HEADSET OVERALL DEPTH | 2.125 INCHES NOMINAL |
| IMPEDANCE RATING IN OHMS | 20000.0 NOMINAL |
| REFERENCE FREQUENCY IN HERTZ | 1000.0 |
| FREQUENCY RESPONSE RANGE IN HERTZ | 850.0 TO 1150.0 |
| ACOUSTIC SENSITIVITY REFERENCE RATING | NOT RATED |
| OUTPUT SENSITIVITY RATING IN DECIBELS | 120.0 |
| MAGNETIC SHIELDING | NOT INCLUDED |
| HEADSET CONNECTING CORD TERMINATION LOCATION | REVERSIBLE RIGHT-LEFT |
| SIGNAL INPUT TERMINAL TYPE | PLUG |
| CONNECTOR MANUFACTURER CODE | 81349 |
| CONNECTOR MANUFACTURER PART NUMBER | PJ055 |
Restrictions/Controls & Freight Information | NSN 5965-00-284-6718
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 062820 | RADIO/TV TRANSMIT/RECEIVE SETS |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 723 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5965-00-284-6718
Army
Navy| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | Q | Electronics Materiel (DLA/GSA Items) |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
| Specific Group/Generic Code | 0 | Medical Materiel |
| Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
| Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
