NSN 5962-01-037-2094 MM5280J5, MM5280J-5, AM9060EDC
Product Details | MEMORY MICROCIRCUIT
5962-01-037-2094 A circuit designed to store information and/or coded instructions. Item has pins or other connections to install in a computer or computing device. Does not include magnetic drums, tapes, punched cards or the like. For items that have portable type connections see MEMORY, PORTABLE, SOLID STATE.
Part Alternates: MM5280J5, MM5280J-5, AM9060EDC, B2107B, P2107C , PD411A, TMS40601JL, TMS4060-1JL, TMS40601JX, TMS4060-1JX, TMS40602JDL, TMS4060-2JDL, TMS40602JL, TMS4060-2JL, TMS4060JL, 02107C4S6007, 500055, 7905360-00, 9S6033115, 9S6033-115, 5962-01-037-2094, 01-037-2094, 5962010372094, 010372094, 790536000
Electrical and Electronic Equipment Components | Microcircuits, Electronic
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 15 MAR 1977 | 01-037-2094 | 41015 ( MICROCIRCUIT, MEMORY ) |
Drawings & Photos | NSN 5962-01-037-2094
Demand History | NSN 5962-01-037-2094
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| P2107C | 2007-06-152 | 100 | United States |
Cross Reference | NSN 5962-01-037-2094
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 02107C4S6007 | 34649 | INTEL CORP SALES OFFICE |
| 500055 | 55760 | ROCKWELL AUTOMATION INTECOLOR |
| 7905360-00 | 90536 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN |
| 9S6033-115 | 46859 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN GOVERNMENT |
| AM9060EDC | 34335 | ADVANCED MICRO DEVICES, INC. DBA A M D |
| B2107B | 34649 | INTEL CORP SALES OFFICE |
| MM5280J-5 | 27014 | NATIONAL SEMICONDUCTOR CORPORATION |
| P2107C | 34649 | INTEL CORP SALES OFFICE |
| PD411A | S0545 | NIPPON ELECTRIC COMPANY LTD - NEC |
| TMS4060-1JL | 01295 | TEXAS INSTRUMENTS INCORPORATED DBA TEXAS INSTRUMENTS |
| TMS4060-1JX | 01295 | TEXAS INSTRUMENTS INCORPORATED DBA TEXAS INSTRUMENTS |
| TMS4060-2JDL | 01295 | TEXAS INSTRUMENTS INCORPORATED DBA TEXAS INSTRUMENTS |
| TMS4060-2JL | 01295 | TEXAS INSTRUMENTS INCORPORATED DBA TEXAS INSTRUMENTS |
| TMS4060JL | 01295 | TEXAS INSTRUMENTS INCORPORATED DBA TEXAS INSTRUMENTS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5962-01-037-2094
Related Products | NSN 5962-01-037-2094
Technical Data | NSN 5962-01-037-2094
| Characteristic | Specifications |
|---|---|
| OUTPUT LOGIC FORM | N-TYPE METAL OXIDE-SEMICONDUCTOR LOGIC |
| INPUT CIRCUIT PATTERN | 15 INPUT |
| (NON-CORE DATA) BIT QUANTITY | 4096 |
| (NON-CORE DATA) WORD QUANTITY | 4096 |
| VOLTAGE RATING AND TYPE PER CHARACTERISTIC | -0.3 VOLTS MINIMUM POWER SOURCE AND 20.0 VOLTS MAXIMUM POWER SOURCE |
| MEMORY DEVICE TYPE | RAM |
| OPERATING TEMP RANGE | -55.0 TO 85.0 DEG CELSIUS |
| TERMINAL TYPE AND QUANTITY | 22 PRINTED CIRCUIT |
| TERMINAL SURFACE TREATMENT | GOLD |
| INCLOSURE CONFIGURATION | DUAL-IN-LINE |
| INCLOSURE MATERIAL | CERAMIC AND GLASS |
| BODY LENGTH | 0.900 INCHES MINIMUM AND 1.100 INCHES MAXIMUM |
| BODY HEIGHT | 0.150 INCHES MINIMUM AND 0.210 INCHES MAXIMUM |
| BODY WIDTH | 0.350 INCHES MINIMUM AND 0.390 INCHES MAXIMUM |
| MAXIMUM POWER DISSIPATION RATING | 1.0 WATTS |
| STORAGE TEMP RANGE | -65.0 TO 150.0 DEG CELSIUS |
| FEATURES PROVIDED | HERMETICALLY SEALED AND MONOLITHIC AND NEGATIVE OUTPUTS AND POSITIVE OUTPUTS AND W/ENABLE AND W/DISABLE |
| III UNPACKAGED UNIT WEIGHT | 5.5 GRAMS |
| III END ITEM IDENTIFICATION | RED ANALOG SWITCH FSCM 04655 |
| III PRECIOUS MATERIAL | GOLD |
| III PRECIOUS MATERIAL AND LOCATION | TERMINALS GOLD |
