NSN 5962-01-077-0391 MMI53311F, MMI5331-1F, HM976032
Product Details | MEMORY MICROCIRCUIT
5962-01-077-0391 A circuit designed to store information and/or coded instructions. Item has pins or other connections to install in a computer or computing device. Does not include magnetic drums, tapes, punched cards or the like. For items that have portable type connections see MEMORY, PORTABLE, SOLID STATE.
Part Alternates: MMI53311F, MMI5331-1F, HM976032, HM9-7603-2, B205119, B2051-19 , CC519019, CC5190-19, S82S123W, SN54S288W00, SN54S288W-00, DH7562819, DH75628-19, ROM/PROM FAMILY 019, ROMPROMFAMILY019, 93282119, 932821-19, 17910, 5962-01-077-0391, 01-077-0391, 5962010770391, 010770391
Electrical and Electronic Equipment Components | Microcircuits, Electronic
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 17 MAY 1979 | 01-077-0391 | 41015 ( MICROCIRCUIT, MEMORY ) |
Drawings & Photos | NSN 5962-01-077-0391
Demand History | NSN 5962-01-077-0391
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 17910 | 2021-01-13 | 1 | US |
| 17910 | 2019-10-287 | 1 | US |
Cross Reference | NSN 5962-01-077-0391
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 17910 | 50364 | MMI/AMD |
| 932821-19 | 82577 | RAYTHEON COMPANY DBA RAYTHEON |
| B2051-19 | 1MY79 | INTERSIL COMMUNICATIONS INC. |
| B2051-19 | 34371 | INTERSIL CORPORATION |
| CC5190-19 | 18324 | PHILIPS SEMICONDUCTORS INC |
| DH75628-19 | 34335 | ADVANCED MICRO DEVICES, INC. DBA A M D |
| HM9-7603-2 | 34371 | INTERSIL CORPORATION |
| MMI5331-1F | 50364 | MMI/AMD |
| ROM/PROM FAMILY 019 | 16236 | DLA LAND AND MARITIME |
| S82S123W | 18324 | PHILIPS SEMICONDUCTORS INC |
| SN54S288W-00 | 01295 | TEXAS INSTRUMENTS INCORPORATED DBA TEXAS INSTRUMENTS |
