NSN 5950-01-178-3254 22022, 2780430010, 278-0430-010
Product Details | RADIO FREQUENCY TRANSFORMER
5950-01-178-3254 An item having either a single tapped winding (autotransformer type), or two or more windings designed to furnish inductive reactance and/or transfer electrical energy in circuits by means of a magnetic field. It is so designed that its entire intended range of operations is above 20 Kilohertz (Kilocycles). The minimum value may extend into the audio frequency range (below 20 Kilohertz). It may include integral capacitors, coils, resistors, and adjustable tuning cores. For items having only two active terminals see COIL, RADIO FREQUENCY. Includes types having windings which may be moved with respect to each other. Excludes TRANSFORMER, DISCRIMINATOR.
Part Alternates: 22022, 2780430010, 278-0430-010, 5950-01-178-3254, 01-178-3254, 5950011783254, 011783254
Electrical and Electronic Equipment Components | Coils and Transformers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 03 MAY 1984 | 01-178-3254 | 00777 ( TRANSFORMER, RADIO FREQUENCY ) |
Drawings & Photos | NSN 5950-01-178-3254
Demand History | NSN 5950-01-178-3254
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 22022 | 2015-03-76 | 200 | TH |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5950-01-178-3254
Technical Data | NSN 5950-01-178-3254
| Characteristic | Specifications |
|---|---|
| TERMINAL TYPE AND QUANTITY | 3 PIN |
| (NON-CORE DATA) WINDING TAP LOCATION | CENTER TAP SINGLE COMPONENT SINGLE PRIMARY |
| RATING METHOD | WINDING TURNS SINGLE COMPONENT SINGLE PRIMARY |
| TURN QUANTITY | 20 SINGLE COMPONENT SINGLE PRIMARY |
| WINDING CONDUCTOR SIZE | 0.00795 INCHES AMERICAN WIRE GAGE SINGLE COMPONENT SINGLE PRIMARY |
| FREQUENCY RATING | 10.0 MEGAHERTZ NOMINAL SINGLE COMPONENT |
| COIL FORM TYPE | SOLID SINGLE COMPONENT |
| WINDING FUNCTION AND QUANTITY | 2 PRIMARY SINGLE COMPONENT |
| MOUNTING METHOD | TERMINAL SINGLE GROUP |
| INCLOSURE TYPE | OPEN |
| BODY OUTSIDE DIAMETER | 0.230 INCHES MAXIMUM |
| BODY HEIGHT | 0.060 INCHES NOMINAL |
| RELIABILITY INDICATOR | NOT ESTABLISHED |
| III MAXIMUM OPERATING TEMP | 125.0 DEG CELSIUS |
Restrictions/Controls & Freight Information | NSN 5950-01-178-3254
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
