5950-01-031-4630 A coil or coils usually constructed with cores having low magnetic reluctance, whose primary purpose is to furnish an inductive impedance in power or audio frequency circuit ranging from zero to 20 kilohertz (kilocycles). Includes audio frequency and power filter chokes, audio reactors and swinging chokes. Does not include transformers or coils used above audio frequency range. Excludes SATURABLE REACTOR. For reactors with air cores, see COIL (as modified).
Part Alternates: 10105, 16036702, 1603670-2, 5950-01-031-4630, 01-031-4630, 5950010314630, 010314630
Electrical and Electronic Equipment Components | Coils and Transformers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 24 NOV 1976 | 01-031-4630 | 00724 ( REACTOR ) |
Drawings & Photos | NSN 5950-01-031-4630
Demand History | NSN 5950-01-031-4630
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 10105 | 2015-03-90 | 2 | PK |
| 10105 | 2013-04-120 | 1 | United Arab Emirates |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5950-01-031-4630
Technical Data | NSN 5950-01-031-4630
| Characteristic | Specifications |
|---|---|
| TERMINAL TYPE AND QUANTITY | 2 TURRET |
| RATING METHOD | ELECTRICAL SINGLE COMPONENT SINGLE WINDING |
| DC RESISTANCE RATING IN OHMS | 4.700 SINGLE COMPONENT SINGLE WINDING |
| INDUCTANCE RATING | 200.00 MICROHENRIES NOMINAL SINGLE COMPONENT SINGLE WINDING |
| WINDING QUANTITY | 1 SINGLE COMPONENT |
| INDUCTANCE TYPE | FIXED |
| MOUNTING METHOD | FLANGE AND UNTHREADED HOLE SINGLE GROUP |
| MOUNTING FACILITY QUANTITY | 2 SINGLE GROUP |
| MOUNTING HOLE DIAMETER | 0.156 INCHES NOMINAL SINGLE GROUP |
| DISTANCE BETWEEN MOUNTING FACILITY CENTERS | 0.516 INCHES NOMINAL SINGLE MOUNTING FACILITY SINGLE CENTER GROUP |
| INCLOSURE TYPE | FULLY INCLOSED |
| BODY LENGTH | 1.000 INCHES MAXIMUM |
| BODY HEIGHT | 0.500 INCHES MAXIMUM |
| BODY WIDTH | 0.500 INCHES MAXIMUM |
| RELIABILITY INDICATOR | NOT ESTABLISHED |
