NSN 5945-01-382-8925 VF415H11S05, VF4-15H11-S05, 12414270004

Product Details | ELECTROMAGNETIC RELAY

5945-01-382-8925 A relay which is actuated by the effect of a magnetic field developed by the current in its energizing coil(s). Includes solenoid and armature types. Excludes CONTACTOR, MAGNETIC; RELAY, METER MOVEMENT; RELAY, MOTOR DRIVEN; RELAY, REED; RELAY, RESONANT REED; RELAY, ROTARY; and SWITCH, STEPPING.

Part Alternates: VF415H11S05, VF4-15H11-S05, 12414270004, 12414270-004, 2649, 5945-01-382-8925, 01-382-8925, 5945013828925, 013828925
