NSN 5945-00-074-3104 SC8083, WKJX196, WKJX-196
Product Details | ELECTROMAGNETIC RELAY
5945-00-074-3104 A relay which is actuated by the effect of a magnetic field developed by the current in its energizing coil(s). Includes solenoid and armature types. Excludes CONTACTOR, MAGNETIC; RELAY, METER MOVEMENT; RELAY, MOTOR DRIVEN; RELAY, REED; RELAY, RESONANT REED; RELAY, ROTARY; and SWITCH, STEPPING.
Part Alternates: SC8083, WKJX196, WKJX-196, R07633G115, RP7633G115, RP7633-G115, RQ7633G115, RQ7633-G115, 2B305425, 2B-3054-25, 342C617H25, 5945-00-074-3104, 00-074-3104, 5945000743104, 000743104
Electrical and Electronic Equipment Components | Relays and Solenoids
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 02 AUG 1967 | 00-074-3104 | 32512 ( RELAY, ELECTROMAGNETIC ) |
Drawings & Photos | NSN 5945-00-074-3104
Demand History | NSN 5945-00-074-3104
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 342C617H25 | 2020-09-259 | 27 | DIBBS |
| RP7633-G115 | 2020-09-259 | 27 | DIBBS |
| WKJX-196 | 2020-09-259 | 27 | DIBBS |
| 342C617H25 | 2020-08-231 | 4 | DIBBS |
| RP7633-G115 | 2020-08-231 | 4 | DIBBS |
| WKJX-196 | 2020-08-231 | 4 | DIBBS |
| 342C617H25 | 2020-07-211 | 4 | DIBBS |
| RP7633-G115 | 2020-07-211 | 4 | DIBBS |
| WKJX-196 | 2020-07-211 | 4 | DIBBS |
| 342C617H25 | 2020-04-110 | 23 | DIBBS |
| RP7633-G115 | 2020-04-110 | 23 | DIBBS |
| WKJX-196 | 2020-04-110 | 23 | DIBBS |
| 5945-00-074-3104 | 2019-07-190 | 3 | US |
| 342C617H25 | 2019-01-07 | 4 | United States |
| 5945-00-074-3104 | 2018-09-272 | 4 | United States |
| 5945-00-074-3104 | 2018-09-267 | 4 | Pakistan |
| 5945-00-074-3104 | 2018-01-18 | 14 | DIBBS |
| 5945-00-074-3104 | 2015-10-281 | 15 | DIBBS |
| 5945-00-074-3104 | 2013-12-352 | 19 | DIBBS |
| 5945-00-074-3104 | 2011-08-213 | 8 | DIBBS |
| 5945-00-074-3104 | 2011-05-143 | 3 | DIBBS |
| 5945-00-074-3104 | 2010-07-202 | 7 | DIBBS |
| 5945-00-074-3104 | 2010-06-165 | 4 | DIBBS |
| 5945-00-074-3104 | 2010-04-103 | 3 | DIBBS |
| 5945-00-074-3104 | 2008-03-64 | 4 | DIBBS |
| 342C617H25 | 2008-01-23 | 20 | PK |
| 5945-00-074-3104 | 2007-10-282 | 11 | DIBBS |
| 5945-00-074-3104 | 2007-02-57 | 3 | DIBBS |
Cross Reference | NSN 5945-00-074-3104
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 2B-3054-25 | 02289 | HI-G CO INC SUB OF NYTRONICS INC |
| 342C617H25 | 97942 | NORTHROP GRUMMAN SYSTEMS CORPORATION DIV NORTHROP GRUMMAN SYSTEMS |
| R07633G115 | 1E9M5 | C P CLARE CORP |
| RP7633-G115 | 00779 | TYCO ELECTRONICS CORPORATION |
| RP7633-G115 | 58614 | TYCO ELECTRONICS CORPORATION DBA CII TECHNOLOGIES |
| RP7633-G115 | D0080 | LEACH INTERNATIONAL GERMANY GMBH |
| RQ7633-G115 | 71482 | CP CLARE CORP NORTH AMERICAN SALES OPERATIONS |
| SC8083 | 77342 | TYCO ELECTRONICS CORPORATION |
| WKJX-196 | 02288 | ALLIED CONTROLS, INC. |
