Product Details | ELECTROMAGNETIC RELAY
5945-00-071-7738 A relay which is actuated by the effect of a magnetic field developed by the current in its energizing coil(s). Includes solenoid and armature types. Excludes CONTACTOR, MAGNETIC; RELAY, METER MOVEMENT; RELAY, MOTOR DRIVEN; RELAY, REED; RELAY, RESONANT REED; RELAY, ROTARY; and SWITCH, STEPPING.
Part Alternates: 4197738, 419773-8, 80124C24, 801-24C24, 8024C24, 80-24C24, 5945-00-071-7738, 00-071-7738, 5945000717738, 000717738
Electrical and Electronic Equipment Components | Relays and Solenoids
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 25 JUL 1967 | 00-071-7738 | 32512 ( RELAY, ELECTROMAGNETIC ) |
Drawings & Photos | NSN 5945-00-071-7738
Demand History | NSN 5945-00-071-7738
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 80-24C24 | 2021-01-24 | 2 | DIBBS |
| 80-24C24 | 2020-09-268 | 2 | DIBBS |
| 80-24C24 | 2020-08-223 | 2 | DIBBS |
| 80-24C24 | 2020-07-211 | 2 | DIBBS |
| 80-24C24 | 2020-04-111 | 9 | DIBBS |
| 80-24C24 | 2019-07-212 | 9 | DIBBS |
| 5945-00-071-7738 | 2018-10-298 | 9 | DIBBS |
| 5945-00-071-7738 | 2018-08-227 | 3 | DIBBS |
| 5945-00-071-7738 | 2013-12-357 | 20 | United States |
| 5945-00-071-7738 | 2013-07-189 | 2 | United States |
Cross Reference | NSN 5945-00-071-7738
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 419773-8 | 96214 | RAYTHEON COMPANY DBA RAYTHEON |
| 80-24C24 | U1918 | FLIGHT REFUELLING LTD DBA COBHAM MACHINE EQUIPMENT |
| 80-24C24 | U3674 | INSYS LTD |
| 801-24C24 | 14195 | INRANGE TECHNOLOGIES CORPORATION DBA MCDATA SERVICES CORPORATION |
| 801-24C24 | U1918 | FLIGHT REFUELLING LTD DBA COBHAM MACHINE EQUIPMENT |
