Product Details | SECTIONAL TERMINAL JUNCTION BLOCK

5940-01-361-8257 An electrical item with multiple socket contacts which may or may not be interconnected by bussing, to form one or more circuits. Item may be of feedback, feedthrough and/or terminating design and may afford a convenient method of interconnection. It may or may not include a sealing grommet. Sectional blocks are normally retained in a track or channel mounting. Excludes CHAMBER, CABLE TERMINAL; CONTACT ASSEMBLY, ELECTRICAL; INSERT, ELECTRICAL CONNECTOR; JUNTION BOX ; TERMINAL BOARD; and TERMINAL BOX.

Part Alternates: R0058004, R00580040301, R0058004-0301 , 10197633, 1585610 , 2HE866, 596.289, 596289, 5940-01-361-8257, 01-361-8257, 5940013618257, 013618257

Electrical and Electronic Equipment Components | Lugs, Terminals, and Terminal Strips

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
59	26 JUL 1992	01-361-8257	32508 ( TERMINAL JUNCTION BLOCK, SECTIONAL )

Drawings & Photos | NSN 5940-01-361-8257
