NSN 5940-00-995-2786 MS171821, MS17182-1, MS25036148
Product Details | LUG TERMINAL
5940-00-995-2786 A terminal designed to be affixed, usually at one end, to a post, stud, chassis, or the like for mounting. It has provisions for attachment of wire(s) or similar electrical conductor(s) in order to establish an electrical connection and could require the use of tool(s) for attachment of wire. For post like terminals, see TERMINAL STUD. Excludes CLIP, ELECTRICAL; TERMINAL, QUICK DISCONNECT and TERMINAL FEEDTHRU.
Part Alternates: MS171821, MS17182-1, MS25036148, MS25036-148, AS25036, AS25036148, AS25036-148, GHN20077046, GHN20077-046 , GT8O5EJ1, 438640448461, 438-6404484-61, 5940-00-995-2786, 00-995-2786, 5940009952786, 211076408, 009952786
Electrical and Electronic Equipment Components | Lugs, Terminals, and Terminal Strips
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 08 APR 1967 | 00-995-2786 | 00746 ( TERMINAL, LUG ) |
Drawings & Photos | NSN 5940-00-995-2786
Demand History | NSN 5940-00-995-2786
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| MS25036148 | 2023-04-108 | 3000 | Romania |
| AS25036 | 2022-09-265 | 5 | Taiwan |
| 5940-00-995-2786 | 2022-03-62 | 50 | United States |
| MS25036148 | 2021-02-34 | 35 | United States |
| 5940-00-995-2786 | 2020-07-202 | 4 | US |
| MS25036148 | 2019-10-295 | 20 | United States |
| 5940-00-995-2786 | 2019-07-206 | 8334 | DIBBS |
| 5940-00-995-2786 | 2019-07-191 | 8334 | DIBBS |
| 5940-00-995-2786 | 2019-03-90 | 8334 | DIBBS |
| AS25036 | 2018-07-183 | 1 | Thailand |
| MS25036148 | 2017-08-220 | 14 | United States |
| MS25036148 | 2016-03-82 | 2 | United States |
| MS25036148 | 2015-08-219 | 72 | United States |
| MS25036-148 | 2015-04-91 | 35 | Greece |
| 5940-00-995-2786 | 2012-09-249 | 8 | United States |
| MS25036-148 | 2012-06-154 | 2 | United Kingdom |
| MS25036148 | 2012-01-12 | 475 | US |
| MS25036148 | 2011-08-235 | 40 | United States |
| 5940-00-995-2786 | 2010-12-349 | 100 | United States |
| 5940-00-995-2786 | 2007-08-242 | 11680 | DIBBS |
| 5940-00-995-2786 | 2007-04-107 | 4938 | DIBBS |
Cross Reference | NSN 5940-00-995-2786
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 211076408 | 53722 | MDH INDUSTRIES INC |
| 438-6404484-61 | 53711 | NAVAL SEA SYSTEMS COMMAND |
| AS25036 | 81343 | SOCIETY OF AUTOMOTIVE ENGINEERS INC |
| AS25036-148 | 81343 | SOCIETY OF AUTOMOTIVE ENGINEERS INC |
| GT8O5EJ1 | 26512 | NORTHROP GRUMMAN SYSTEMS CORPORATION DIV NORTHROP GRUMMAN AEROSPACE |
| MS17182-1 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| MS25036-148 | 81343 | SOCIETY OF AUTOMOTIVE ENGINEERS INC |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5940-00-995-2786
Related Products | NSN 5940-00-995-2786
Technical Data | NSN 5940-00-995-2786
| Characteristic | Specifications |
|---|---|
| BASIC SHAPE STYLE | A24 CRIMP |
| OVERALL LENGTH | 0.653 INCHES |
| OVERALL WIDTH | 0.218 INCHES |
| MATERIAL THICKNESS | 0.035 INCHES |
| CONDUCTOR ACCOMMODATION TYPE | STRAIGHT BARREL SINGLE END |
| MAXIMUM CONDUCTOR SIZE ACCOMMODATED | 16 AWG |
| MOUNTING METHOD STYLE | D14 RING |
| MOUNTING HOLE DIAMETER | 0.122 INCHES |
| MOUNTING TONGUE WIDTH | 0.182 INCHES |
| MOUNTING FACILITY THICKNESS | 0.035 INCHES |
| ELECTRICAL INSULATION FEATURE | INSULATING SLEEVE |
| IDENTIFICATION CODE COLOR | GREEN |
| MATERIAL | COPPER CONDUCTOR ACCOMMODATION PLASTIC POLYAMIDE INSULATION COPPER MOUNTING FACILITY |
| MATERIAL DOCUMENT AND CLASSIFICATION | QQ-C-576 FED SPEC SINGLE MATERIAL RESPONSE CONDUCTOR ACCOMMODATION QQ-C-576 FED SPEC SINGLE MATERIAL RESPONSE MOUNTING FACILITY |
| SURFACE TREATMENT | TIN CONDUCTOR ACCOMMODATION SINGLE LAYER TIN MOUNTING FACILITY SINGLE LAYER |
| TEST DATA DOCUMENT | 96906-MS17182 SPECIFICATION |
Restrictions/Controls & Freight Information | NSN 5940-00-995-2786
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061680 | ELEC WIRING PLUGS ETC |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 658 | unknown |
| Originating Activity Code | CX | Defense Supply Center Richmond Richmond, VA 23297-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
