NSN 5940-00-346-7689 7666377, 00-346-7689, 003467689
Product Details | RADIO FREQUENCY GROUNDING CONTACT STRIP
5940-00-346-7689 A semirigid metallic item of electrically conductive material designed for the specific purpose of grounding and/or bonding radio frequency equipment. It is normally attached to one item to give spring action to form a ground and/or bond with another item. Excludes TERMINAL STRIP, GROUNDING; CONTACT, ELECTRICAL; and STRIP, ELECTRICAL GROUNDING.
Part Alternates: 7666377, 5940-00-346-7689, 00-346-7689, 5940003467689, 003467689
Electrical and Electronic Equipment Components | Lugs, Terminals, and Terminal Strips
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1963 | 00-346-7689 | 22600 ( CONTACT STRIP, RADIO FREQUENCY GROUNDING ) |
Cross Reference | NSN 5940-00-346-7689
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 7666377 | 19200 | US ARMY ARDEC RDECOM |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5940-00-346-7689
Technical Data | NSN 5940-00-346-7689
| Characteristic | Specifications |
|---|---|
| UNIT TYPE | PLATE |
| CONTACT FINGER QUANTITY | 21 |
| MATERIAL | BERYLLIUM COPPER, QQ-C-533, COMP HT |
| SURFACE TREATMENT | SILVER PLATED |
| OVERALL LENGTH | 3.562 INCHES NOMINAL |
| OVERALL WIDTH | 0.875 INCHES NOMINAL |
| OVERALL THICKNESS | 0.010 INCHES NOMINAL |
| MOUNTING METHOD | HOLE |
| MOUNTING CONFIGURATION | 3 HOLES 0.156 DIA SPACED UNEVENLYALONG LENGTH OPPOSITE CONTACTS |
| III PRECIOUS MATERIAL | SILVER |
| III PRECIOUS MATERIAL AND LOCATION | OVERALL SILVER |
| III FSC APPLICATION DATA | LOCAL CONTROL SYSTEM,A/A GUN |
| MANUFACTURERS CODE | 19200 |
| DESIGN CONTROL REFERENCE | 7666377 |
Restrictions/Controls & Freight Information | NSN 5940-00-346-7689
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | S | Item contains silver |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
