NSN 5935-01-330-0615 FS91301, FS9-1301, 45049272
Product Details | ELECTRICAL CONNECTOR RETAINING PLATE
5935-01-330-0615 A flat metallic item varied in shape with an opening(s) to accommodate an electrical connector(s). It must have facilities for mounting. Used to position an electrical connector. See also PLATE, MOUNTING (as modified). Excludes PLATE, WALL, ELECTRICAL and ESCUTCHEON PLATE.
Part Alternates: FS91301, FS9-1301, 45049272, 4504927-2, 5935-01-330-0615, 01-330-0615, 5935013300615, 013300615
Electrical and Electronic Equipment Components | Connectors, Electrical
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 29 NOV 1990 | 01-330-0615 | 21538 ( PLATE, RETAINING, ELECTRICAL CONNECTOR ) |
Drawings & Photos | NSN 5935-01-330-0615
Demand History | NSN 5935-01-330-0615
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 4504927-2 | 2024-08-214 | 238 | DIBBS |
| FS9-1301 | 2024-08-214 | 238 | DIBBS |
| 5935-01-330-0615 | 2024-02-52 | 1 | US |
| 5935-01-330-0615 | 2022-10-297 | 25 | VI |
| 5935-01-330-0615 | 2022-06-163 | 180 | Turkey |
| 5935-01-330-0615 | 2022-04-104 | 250 | US |
| 4504927-2 | 2022-03-90 | 156 | DIBBS |
| FS9-1301 | 2022-03-90 | 156 | DIBBS |
| 5935-01-330-0615 | 2020-08-239 | 10 | US |
| 5935-01-330-0615 | 2017-11-326 | 30 | UM |
| 5935-01-330-0615 | 2016-11-321 | 2 | United States |
| 5935-01-330-0615 | 2013-05-123 | 86 | DIBBS |
| 5935-01-330-0615 | 2011-07-210 | 62 | DIBBS |
| 5935-01-330-0615 | 2011-05-131 | 24 | DIBBS |
| 5935-01-330-0615 | 2011-02-48 | 75 | United States |
| 5935-01-330-0615 | 2010-11-316 | 20 | DIBBS |
| 5935-01-330-0615 | 2009-03-75 | 20 | DIBBS |
| 5935-01-330-0615 | 2008-11-330 | 23 | DIBBS |
| FS91301 | 2007-11-316 | 1000 | India |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5935-01-330-0615
Related Products | NSN 5935-01-330-0615
Technical Data | NSN 5935-01-330-0615
| Characteristic | Specifications |
|---|---|
| STYLE DESIGNATOR | 10J SQUARE SHAPE |
| OVERALL LENGTH | 1.138 INCHES NOMINAL |
| CENTER TO CENTER DISTANCE BETWEEN MOUNTING FACILITIES PARALLEL TO LENGTH | 0.840 INCHES MINIMUM AND 0.846 INCHES MAXIMUM |
| CENTER TO CENTER DISTANCE BETWEEN MOUNTING FACILITIES PARALLEL TO WIDTH | 0.840 INCHES MINIMUM AND 0.846 INCHES MAXIMUM |
| OVERALL HEIGHT | 0.106 INCHES MINIMUM AND 0.166 INCHES MAXIMUM |
| OVERALL WIDTH | 1.138 INCHES NOMINAL |
| MATERIAL | ALUMINUM ALLOY |
| SURFACE TREATMENT | CHROMATE |
| MOUNTING FACILITY TYPE AND QUANTITY | 4 THREADED HOLE |
| THREAD SERIES DESIGNATOR | UNJC |
| NOMINAL THREAD SIZE | 0.112 INCHES |
| THREAD CLASS | 3B |
| THREAD QUANTITY PER INCH | 40 |
| THREAD DIRECTION | RIGHT-HAND |
| SIZE DESIGNATION | 13 |
| SPECIAL FEATURES | 0.550 IN. CUTOUT ON ONE SIDE |
