NSN 5935-01-108-4483 MS3116E1419P, MS3116E14-19P, MS3116F1419P

Product Details | ELECTRICAL PLUG CONNECTOR

5935-01-108-4483 An electrical fitting with electrical contacts, constructed to be affixed to the end of a cable, conduit, coaxial line, cord or wiring for convenience in joining with other electrical connector(s) or PRINTED WIRING BOARD and is not designed to be mounted on a bulkhead, chasses, panel, PRINTED WIRING BOARD, or the like. Excludes JACK, TELEPHONE; JACK, TIP; PLUG, TELEPHONE; PLUG TIP; INSERT, ELECTRICAL CONNECTOR; CONNECTOR BODY (as modified); and SOCKET, PLUG-IN, ELECTRONIC COMPONENTS. See also LEAD ASSEMBLY, ELECTRICAL; WIRING HARNESS (as modified); and CABLE ASSEMBLY (as modified). For items without inserts, see SHELL, ELECTRICAL CONNECTOR.

Part Alternates: MS3116E1419P, MS3116E14-19P, MS3116F1419P, MS3116F14-19P, MS3126F1419P, MS3126F14-19P, MS3126L1419P, MS3126L14-19P, MS3126P1419P, MS3126P14-19P, MS3476L1419P, MS3476L14-19P, MS3476L1419PN, MS3476L14-19PN, MS3476W1419P, MS3476W14-19P, MS3476W1419PN, MS3476W14-19PN, M83723/14R1419N, M83723/14W419, M8372314R1419N, M8372314W419, MB16A1419PN, MB16A-1419PN, MB16W1419PN, ASC1105188, DBA561419PN043, DBA56-14-19PN043, EA111419PE, EA1114-19PE, G0050503, MILC26482, MIL-C-26482, PT06A1419PSR, PV6R14B19PNL, X215421419P, X21-542-14-19P, 10502531, 4142184014, 414-2184-014, 810BA0946, 5935-01-108-4483, 01-108-4483, 5935011084483, 011084483

Electrical and Electronic Equipment Components | Connectors, Electrical

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
59	27 FEB 1981	01-108-4483	01938 ( CONNECTOR, PLUG, ELECTRICAL )

Drawings & Photos | NSN 5935-01-108-4483

Part Number	Request Date	QTY	Origin
MS3476W1419P	2021-05-05	6	United States
5935-01-108-4483	2020-04-30	10	US
5935-01-108-4483	2018-02-01	5201	DIBBS
5935-01-108-4483	2017-12-22	5	US
MS3476W1419P	2017-12-21	1	us
MS3476W1419P	2017-07-28	1	us
MS3476L1419P	2017-03-20	1	United States
5935-01-108-4483	2016-04-20	9900	DIBBS
5935-01-108-4483	2016-04-05	1887	DIBBS
MS3476L1419P	2014-12-29	18	United States
MS3476W14-19P	2014-05-07	27	United States
MS3476W1419P	2013-09-10	6	United States
5935-01-108-4483	2013-02-28	2000	DIBBS
MS3126F14-19P	2012-11-05	49
MS3476W14-19P	2012-09-20	30
MS3476W1419P	2012-07-23	14	US
5935-01-108-4483	2012-04-27	20	PK
MS3126F14-19P	2012-04-27	20	PK
MS3126F14-19P	2012-04-24	20	PK
5935-01-108-4483	2012-01-29	1	Malaysia
5935-01-108-4483	2012-01-29	10	Malaysia
MS3476L14-19P	2011-11-11	500
MS3476W1419P	2011-09-28	47	Taiwan
MS3116E1419P	2011-02-17	10	Korea
MILC26482	2011-01-27	4	Portugal
5935-01-108-4483	2010-09-27	3576	DIBBS
5935-01-108-4483	2010-07-28	393	DIBBS
5935-01-108-4483	2010-05-20	1351	DIBBS
MS3476W1419P	2010-05-19	10	US
5935-01-108-4483	2010-03-29	986	DIBBS
5935-01-108-4483	2009-09-08	676	DIBBS
5935-01-108-4483	2009-06-24	652	DIBBS
5935-01-108-4483	2009-05-05	920	DIBBS
5935-01-108-4483	2009-04-30	1062	DIBBS
5935-01-108-4483	2009-03-16	1900	DIBBS
5935-01-108-4483	2007-03-14	2	South Korea

Cross Reference | NSN 5935-01-108-4483

Part Number	Cage Code	Manufacturer
10502531	56161	GENERAL DYNAMICS LAND SYSTEMS - CANADA CORPORATION
414-2184-014	94756	BOEING COMPANY, THE DBA BOEING
810BA0946	A0199	OTO MELARA SPA
ASC1105188	Z4779	ASC PTY LTD
DBA56-14-19PN043	11139	DEUTSCH ENGINEERED CONNECTING DEVICES INC
EA1114-19PE	49367	AMPHENOL CORPORATION DBA AMPHENOL AEROSPACE INDUSTRIAL
G0050503	U6682	SELEX ES LTD
M83723/14R1419N	81349	MILITARY SPECIFICATIONS PROMULGATED BY MILITARY
M83723/14W419	81349	MILITARY SPECIFICATIONS PROMULGATED BY MILITARY
MB16A-1419PN	14283	AMPHENOL OPTIMIZE MANUFACTURING CO. DIV AMPHENOL AEROSPACE OPERATIONS
MB16W1419PN	14283	AMPHENOL OPTIMIZE MANUFACTURING CO. DIV AMPHENOL AEROSPACE OPERATIONS
MIL-C-26482	81349	MILITARY SPECIFICATIONS PROMULGATED BY MILITARY
MS3116E14-19P	96906	MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS
MS3116F14-19P	96906	MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS
MS3126F14-19P	96906	MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS
MS3126L14-19P	96906	MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS
MS3126P14-19P	96906	MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS
MS3476L14-19P	96906	MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS
MS3476L14-19PN	96906	MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS
MS3476W14-19P	81349	MILITARY SPECIFICATIONS PROMULGATED BY MILITARY
MS3476W14-19P	96906	MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS
MS3476W14-19PN	96906	MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS
PT06A-14-19P(SR)	05063	AVNET INC HAMILTON/AVNET ELECTRONICS DIV
PT06A-14-19P(SR)	20441	POWELL ELECTRONICS INC.
PV6R14B19PNL	71468	ITT CORPORATION DBA I T T CANNON
X21-542-14-19P	S3712	BAE SYSTEMS BOFORS AB
X21-542-14-19P	S3715	BOFORS AB

Request a Quote

What Our Customers Say

Thank you very much for the excellent service and professional customer care.

Ernie G. Honeywell

The service was excellent. I can think of no improvements to date that you can make regarding internet sales.

John L. Raytheon

The representative for WBParts was efficient & handled our request in a timely & professional manner.

Karen G. General Dynamics

Tried two other sources, neither of them responded, was all done online, never spoke to anyone.

Rex S. US Airforce

The response is quick and the price is often very good. We are completely satisfied.

Patricia S. NASA

Compare

NSNs for Compare ( up to 4 ): Add 5935-01-108-4483

Compare

Related Products | NSN 5935-01-108-4483

5935-01-108-4484, 5935-01-108-4485, 5935-01-108-4486, 5935-01-108-4487, 5935-01-108-4488

Technical Data | NSN 5935-01-108-4483

Characteristic	Specifications
BODY STYLE	7A STRAIGHT SHAPE, INTERNAL COUPLING
OVERALL LENGTH	1.230 INCHES MAXIMUM
OVERALL DIAMETER	1.183 INCHES MAXIMUM
CONNECTOR LOCKING METHOD	BAYONET LATCH
SHELL TYPE	SOLID
SHELL MATERIAL	ALUMINUM ALLOY
SHELL MATERIAL DOCUMENT AND CLASSIFICATION	QQ-A-591 FED SPEC SINGLE MATERIAL RESPONSE
SHELL SURFACE TREATMENT	CADMIUM
SHELL SURFACE TREATMENT DOCUMENT AND CLASSIFICATION	QQ-P-416 FED SPEC SINGLE TREATMENT RESPONSE
POLARIZATION METHOD	KEYWAY OR MULTIPLE KEYWAY
INSERT POSITION IN DEG	0.0
MATING END QUANTITY	1
CONTACT POSITION ARRANGEMENT STYLE	AVAB 14-19 SINGLE MATING END
INCLUDED CONTACT QUANTITY	19 SINGLE MATING END SINGLE CONTACT GROUPING
CONTACT REMOVABILITY	REMOVABLE SINGLE MATING END SINGLE CONTACT GROUPING
INCLUDED CONTACT TYPE	ROUND PIN SINGLE MATING END SINGLE CONTACT GROUPING
CONTACT MAXIMUM AC VOLTAGE RATING IN VOLTS	1000.0 SINGLE MATING END SINGLE CONTACT GROUPING
CONTACT SURFACE TREATMENT	GOLD AND NICKEL SINGLE MATING END SINGLE CONTACT GROUPING
CONTACT SURFACE TREATMENT DOCUMENT AND CLASSIFICATION	MIL-G-45204,TY 1,CL 1,GRADE C MIL SPEC 1ST TREATMENT RESPONSE AND QQ-N-290,GRADE E FED SPEC 2ND TREATMENT RESPONSE SINGLE MATING END SINGLE CONTACT GROUPING
TERMINAL TYPE	CRIMP SINGLE MATING END SINGLE CONTACT GROUPING
TERMINAL LOCATION	BACK SINGLE MATING END SINGLE CONTACT GROUPING
ENVIRONMENTAL PROTECTION	MOISTURE PROOF AND SALT WATER RESISTANT AND VIBRATION PROOF
SPECIAL FEATURES	IN ORDER TO COMPLETE THE CONNECTOR ASSEMBLY,THE USER MUST OBTAIN/PROVIDE THE BACKSHELL; STANDARD VERSIONS MAY BE ORDERED AS NSN 5935-01-163-3224,P/N M85049/52-1-14W FOR THE STRAIGHT STYLE,OR NSN 5935-01-186-5612,P/N M85049/51-1-14W FOR THE RIGHT ANGLE STYLE
TEST DATA DOCUMENT	81349-MIL-C-26482 SPECIFICATION
SPECIFICATION/STANDARD DATA	96906-MS3476 GOVERNMENT STANDARD
III PRECIOUS MATERIAL	GOLD
III PRECIOUS MATERIAL AND WEIGHT	0.019 GOLD GRAINS, TROY
III PRECIOUS MATERIAL AND LOCATION	CONTACT SURFACES GOLD
MANUFACTURERS CODE	81349
NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE	MIL-C-26482
MANUFACTURERS CODE	96906
DEFINITIVE GOVERNMENT SPEC/STD REFERENCE	MS3476W14-19P

Restrictions/Controls & Freight Information | NSN 5935-01-108-4483

Restrictions
Freight

Category	Code	Description
Shelf-Life Code:	0	Nondeteriorative
Hazardous Material Indicator Code	P	There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product
Demilitarization Code:	A	Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:	U	UNCLASSIFIED
Electro-static Discharge Susceptible:	A	No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity
Precious Metals Indicator Code:	G	Item contains gold
Criticality Code:	X	The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:	0	Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)

Category	Code	Description
NMF Description	061680	ELEC WIRING PLUGS ETC
Less than car load rating
Less than truck load rating	W	Rating Variable
Water commodity Code	658	unknown
Originating Activity Code	TX	Defense Supply Center Columbus Columbus, OH 43218
Air Dimension Code	A	Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity	H	Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc.
Air Special Handling	Z	No special handling required.
Special Handling Code	9	unknonwn
HAZMAT
Type of Cargo	Z	No special type of cargo code applicable

Management | NSN 5935-01-108-4483

Category	Code	Description
Materiel Category and Inventory Manager	Q	Electronics Materiel (DLA/GSA Items)
Appropriation and Budget Activity	2	Stock Fund Secondary Items
Management Inventory Segment	2	NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable.
Specific Group/Generic Code	0	Medical Materiel
Weapons Systems/End Item or Homogeneous Group	00	DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
Accounting Requirements Code	X	Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items.
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DA	Department of the Army
Service Organization	A	U.S. Army
Reparability	Z	This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item.
Acquisition Advice Codes	D	DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	0	Nondeteriorative
Purchasing	QTY UOM	1 EA : Each

Category	Code	Description
Budget Code	9	General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors.
Materiel Management Aggregation Code	EH	SX:ELECTRONIC COMPONENTS
Price Validation	N	The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM. The price has not been analyzed or reviewed for accuracy. ZOP or Standard price challenges are permissible, but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of ?L? or?F?,the case must be evaluated locally where purchased or fabricated.
Fund Code	SF	Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point.
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DF	Department of the Air Force
Service Organization	F	U.S. Air Force
Reparability	N	Stock Fund (except Munitions)
Acquisition Advice Codes	D	DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	0	Nondeteriorative
Purchasing	QTY UOM	1 EA : Each

Category	Code	Description
Stores Account Code	1	Marine Corps Stock Fund Account Item.
Combat Essentiality Code	6	Critical Repair Part to a Non-Combat Essential End Item. Those parts or components whose failure in a noncombat essential end item will render the end item inoperative or reduce its effectiveness below the minimum acceptable level of efficiency.
Materiel Management Code	B	All CommoditiesDefense Logistics Agency, (DLA,)
Echelon Management Code	2	ICP/DSSC Marine Corps-managed Recoverability Code D items and Defense Logistics Agency (DLA)/TACOM/GSA) items which the integrated manager has not decontrolled.
Echelon Identification Code	B	Consumable Repair Parts
Physical Category Code	1	Bin
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DM	U.S. Marine Corps
Service Organization	M	U.S. Marine Corps
Reparability	Z	Nonreparable item. When unserviceable, condemn and dispose at the level indicated by the first digit of the maintenance code.
Acquisition Advice Codes	D	DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	0	Nondeteriorative
Purchasing	QTY UOM	1 EA : Each

Category	Code	Description
Cognizance Codes	9B	Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg
Special Material Content	9	Non-Hazardous or Non-Sensitive Item, does not require hazardous or special handling, packaging or precautions
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DN	Department of the Navy
Service Organization	N	U.S. Navy
Acquisition Advice Codes	D	DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	0	Nondeteriorative
Purchasing	QTY UOM	1 EA : Each
