Product Details | ELECTRICAL CONNECTOR INSERT

5935-01-055-6310 An insulating element with or without contact(s) designed to fit into an ADAPTER (2), CONNECTOR; CONNECTOR BODY, PLUG, ELECTRICAL; CONNECTOR BODY, RECEPTACLE, ELECTRICAL; CONNECTOR, PLUG, ELECTRICAL; or CONNECTOR, RECEPTACLE, ELECTRICAL forming an integral liner or seat. Excludes INSULATOR (1), DISK; INSULATOR (1) PLATE; TERMINAL (1), FEEDTHRU and TERMINAL BOARD. See also CONNECTOR (as modified); CONNECTOR BODY (as modified); and INSERT MODULE, ELECTRICAL CONNECTOR.

Part Alternates: MTCB1XXXX106, MTCB1X-XXX-106, 16VE04901012, 16VE049010-12, 5935-01-055-6310, 01-055-6310, 5935010556310, 010556310

Electrical and Electronic Equipment Components | Connectors, Electrical
