NSN 5935-01-024-2809 1003295-01, 2060391, 206039-1
Product Details | ELECTRICAL PLUG CONNECTOR BODY
5935-01-024-2809 The main or principal part of a CONNECTOR, PLUG, ELECTRICAL which includes insert(s) designed to accommodate but does not include removable contacts. It may have a hood or shell, a jackscrew and jacksocket, or other means for polarizing and aligning. It is not designed to be mounted on a bulkhead, chassis, panel, wall, or the like. Excludes CONNECTOR BODY, MODULAR PLUG, ELECTRICAL. For items without insert(s), see SHELL, ELECTRICAL CONNECTOR.
Part Alternates: 1003295-01, 2060391, 206039-1, 4150010002, 415-0010-002, 5400416, 5935-01-024-2809, 01-024-2809, 5935010242809, 100329501, 010242809
Electrical and Electronic Equipment Components | Connectors, Electrical
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 08 JUL 1976 | 01-024-2809 | 61924 ( CONNECTOR BODY, PLUG, ELECTRICAL ) |
Drawings & Photos | NSN 5935-01-024-2809
Demand History | NSN 5935-01-024-2809
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5935-01-024-2809 | 2010-10-291 | 38 | DIBBS |
| 5935-01-024-2809 | 2010-10-291 | 70 | DIBBS |
Cross Reference | NSN 5935-01-024-2809
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 1003295-01 | 1PQF4 | L-3 COMMUNICATIONS CORPORATION DBA LINK SIMULATION & TRAINING |
| 1003295-01 | 36378 | RAYTHEON TECHNICAL SERVICES COMPANY |
| 206039-1 | 00779 | TYCO ELECTRONICS CORPORATION |
| 415-0010-002 | 14304 | HARRIS CORPORATION DBA HARRIS RF COMMUNICATION |
| 5400416 | 53711 | NAVAL SEA SYSTEMS COMMAND |
