NSN 5935-00-552-6791 A-531, SYM 2841, SYM2841
Product Details | JACK BOX
5935-00-552-6791 An enclosure which includes, mounts, and protects one or more jacks. It is designed for and may include the cover and such accessories as mounting hardware, brackets, locks, and conduit fittings. May include terminal boards specifically used as a convenience for terminating the jacks. For boxes which include combinations of different electrical devices such as switches, fuseholders, jacks, circuit breakers, terminal boards and the like, see DISTRIBUTION BOX. For boxes which are designed to mount, but which do not include jacks, see JUNCTION BOX.
Part Alternates: A-531, SYM 2841, SYM2841, G-15A, G15A/SYM2841, G15ASYM2841, G15A, 4042841, 404-2841, 9000803H74210, 9000-803H74210, 9000S650/H74210/G-15, 9000S650174210, 9000-S6501-74210, 9000S650174210G15A, 9000-S6501-74210G15A, 9000S650174210REVF, 9000-S6501-74210REVF, 9000S6501-74210REVF, 9000S650174210REVH, 9000-S6501-74210REVH, 9000S6501H74210/G-15A, 9000S6501H74210G15A, 9000S650H74210G15, A531, 5935-00-552-6791, 00-552-6791, 5935005526791, 005526791
Electrical and Electronic Equipment Components | Connectors, Electrical
Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
---|---|---|---|
59 | 01 JAN 1963 | 00-552-6791 | 16136 ( JACK BOX ) |
Demand History | NSN 5935-00-552-6791
Part Number | Request Date | QTY | Origin |
---|---|---|---|
5935-00-552-6791 | 2024-07-188 | 2 | United States |
5935-00-552-6791 | 2024-07-186 | 2 | US |
404-2841 | 2024-06-177 | 702 | DIBBS |
9000S6501H74210/G-15A | 2024-06-177 | 702 | DIBBS |
SYM 2841 | 2024-06-177 | 702 | DIBBS |
5935-00-552-6791 | 2024-05-137 | 100 | ES |
5935-00-552-6791 | 2024-05-131 | 1 | US |
404-2841 | 2024-05-123 | 171 | DIBBS |
9000S6501H74210/G-15A | 2024-05-123 | 171 | DIBBS |
SYM 2841 | 2024-05-123 | 171 | DIBBS |
404-2841 | 2024-04-108 | 171 | DIBBS |
9000S6501H74210/G-15A | 2024-04-108 | 171 | DIBBS |
SYM 2841 | 2024-04-108 | 171 | DIBBS |
404-2841 | 2024-03-87 | 809 | DIBBS |
9000S6501H74210/G-15A | 2024-03-87 | 809 | DIBBS |
SYM 2841 | 2024-03-87 | 809 | DIBBS |
5935-00-552-6791 | 2024-03-85 | 7 | United States |
5935-00-552-6791 | 2024-03-64 | 12 | United States |
5935-00-552-6791 | 2024-02-51 | 12 | United States |
404-2841 | 2024-02-43 | 415 | DIBBS |
9000S6501H74210/G-15A | 2024-02-43 | 415 | DIBBS |
SYM 2841 | 2024-02-43 | 415 | DIBBS |
404-2841 | 2024-01-21 | 186 | DIBBS |
9000S6501H74210/G-15A | 2024-01-21 | 186 | DIBBS |
SYM 2841 | 2024-01-21 | 186 | DIBBS |
404-2841 | 2023-12-360 | 229 | DIBBS |
9000S6501H74210/G-15A | 2023-12-360 | 229 | DIBBS |
SYM 2841 | 2023-12-360 | 229 | DIBBS |
404-2841 | 2023-12-348 | 229 | DIBBS |
9000S6501H74210/G-15A | 2023-12-348 | 229 | DIBBS |
SYM 2841 | 2023-12-348 | 229 | DIBBS |
5935-00-552-6791 | 2023-06-181 | 5 | United States |
404-2841 | 2023-06-180 | 273 | DIBBS |
9000S6501H74210/G-15A | 2023-06-180 | 273 | DIBBS |
SYM 2841 | 2023-06-180 | 273 | DIBBS |
404-2841 | 2023-05-130 | 477 | DIBBS |
9000S6501H74210/G-15A | 2023-05-130 | 477 | DIBBS |
SYM 2841 | 2023-05-130 | 477 | DIBBS |
5935-00-552-6791 | 2023-02-46 | 2 | US |
404-2841 | 2022-07-212 | 317 | DIBBS |
9000S6501H74210/G-15A | 2022-07-212 | 317 | DIBBS |
SYM 2841 | 2022-07-212 | 317 | DIBBS |
404-2841 | 2022-07-198 | 240 | DIBBS |
9000S6501H74210/G-15A | 2022-07-198 | 240 | DIBBS |
SYM 2841 | 2022-07-198 | 240 | DIBBS |
404-2841 | 2022-06-174 | 240 | DIBBS |
9000S6501H74210/G-15A | 2022-06-174 | 240 | DIBBS |
SYM 2841 | 2022-06-174 | 240 | DIBBS |
5935-00-552-6791 | 2022-01-17 | 1 | Japan |
5935-00-552-6791 | 2021-08-228 | 3 | Saudi Arabia |
5935-00-552-6791 | 2021-01-14 | 15 | TW |
SYM2841 | 2020-10-289 | 1 | United States |
5935-00-552-6791 | 2020-03-84 | 4 | US |
404-2841 | 2020-03-61 | 230 | DIBBS |
9000S6501H74210/G-15A | 2020-03-61 | 230 | DIBBS |
SYM 2841 | 2020-03-61 | 230 | DIBBS |
5935-00-552-6791 | 2020-02-36 | 2 | Saudi Arabia |
5935-00-552-6791 | 2020-02-36 | 2 | Saudi Arabia |
404-2841 | 2020-02-35 | 444 | DIBBS |
9000S6501H74210/G-15A | 2020-02-35 | 444 | DIBBS |
SYM 2841 | 2020-02-35 | 444 | DIBBS |
5935-00-552-6791 | 2020-01-28 | 1 | US |
5935-00-552-6791 | 2019-04-120 | 5 | United States |
5935-00-552-6791 | 2017-12-355 | 2 | United States |
5935-00-552-6791 | 2014-11-313 | 400 | DIBBS |
5935-00-552-6791 | 2014-09-247 | 5 | Saudi Arabia |
5935-00-552-6791 | 2014-07-205 | 273 | DIBBS |
5935-00-552-6791 | 2014-04-108 | 365 | DIBBS |
5935-00-552-6791 | 2014-04-97 | 365 | DIBBS |
5935-00-552-6791 | 2014-03-64 | 422 | DIBBS |
5935-00-552-6791 | 2012-11-306 | 2 | Taiwan |
5935-00-552-6791 | 2012-04-95 | 1 | US |
5935-00-552-6791 | 2012-03-68 | 0 | DIBBS |
5935-00-552-6791 | 2012-03-62 | 197 | DIBBS |
5935-00-552-6791 | 2011-12-353 | 161 | DIBBS |
5935-00-552-6791 | 2011-10-276 | 0 | DIBBS |
5935-00-552-6791 | 2011-09-266 | 188 | DIBBS |
5935-00-552-6791 | 2010-10-279 | 3 | US |
5935-00-552-6791 | 2010-04-97 | 607 | South Korea |
5935-00-552-6791 | 2010-03-83 | 320 | Turkey |
5935-00-552-6791 | 2008-08-218 | 325 | DIBBS |
5935-00-552-6791 | 2008-06-176 | 310 | DIBBS |
5935-00-552-6791 | 2008-04-92 | 360 | DIBBS |
5935-00-552-6791 | 2007-12-354 | 200 | DIBBS |
5935-00-552-6791 | 2007-11-317 | 80 | DIBBS |
5935-00-552-6791 | 2007-09-264 | 114 | DIBBS |
5935-00-552-6791 | 2007-08-239 | 138 | DIBBS |
5935-00-552-6791 | 2007-05-129 | 95 | DIBBS |
Cross Reference | NSN 5935-00-552-6791
Part Number | Cage Code | Manufacturer |
---|---|---|
404-2841 | 57626 | COMSACO, INC. |
9000-803H74210 | 80064 | NAVAL SHIP SYSTEMS COMMAND |
9000-S6501-74210 | 28003 | WINCHESTER INDUSTRIES INC |
9000-S6501-74210G15A | 80064 | NAVAL SHIP SYSTEMS COMMAND |
9000-S6501-74210REVF | 45516 | PALMER ELECTRIC CO |
9000-S6501-74210REVH | 80064 | NAVAL SHIP SYSTEMS COMMAND |
9000S650/H74210/G-15 | 14100 | STROMBERG-CARLSON CORP A PLESSEY TELECOMMUNICATIONS CO |
9000S6501-74210REVF | 82305 | PALMER ELECTRONICS CORP |
9000S6501H74210/G-15A | 14100 | STROMBERG-CARLSON CORP A PLESSEY TELECOMMUNICATIONS CO |
9000S6501H74210/G-15A | 28003 | WINCHESTER INDUSTRIES INC |
9000S6501H74210/G-15A | 44291 | U.S. PIONEER, L.L.C. DBA U.S. PIONEER |
9000S6501H74210/G-15A | 58475 | WESTWOOD CORPORATION DBA NMP DIVISION |
9000S6501H74210/G-15A | 5Y945 | SPARTAN MFG CO |
9000S6501H74210/G-15A | 73274 | HOSE-MCCANN TELEPHONE CO., INC. DBA HOSE MCCANN COMMUNICATIONS |
9000S6501H74210/G-15A | 77096 | PALMER ELECTRIC CO DIV TABET MFG CO INC |
9000S6501H74210/G-15A | 88829 | TABET MANUFACTURING COMPANY, INC. |
A-531 | 03950 | NAVAL INVENTORY CONTROL POINT MECHANICSBURG |
G-15A | 50726 | EXELIS INC. |
G15A | 73274 | HOSE-MCCANN TELEPHONE CO., INC. DBA HOSE MCCANN COMMUNICATIONS |
G15A | 96169 | ELECTRIC BOAT CORPORATION |
G15A/SYM2841 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
SYM 2841 | 03950 | NAVAL INVENTORY CONTROL POINT MECHANICSBURG |
SYM 2841 | 57626 | COMSACO, INC. |
SYM2841 | 81898 | SUPERVISOR OF SHIPBUILDING CONVERSION AND REPAIR USN |
Request a Quote
What Our Customers Say
Compare
Related Products | NSN 5935-00-552-6791
Technical Data | NSN 5935-00-552-6791
Characteristic | Specifications |
---|---|
STYLE DESIGNATOR | 6A RECTANGULAR, SURFACE MOUNTING |
OVERALL DEPTH | 3.750 INCHES NOMINAL |
OVERALL HEIGHT | 4.625 INCHES NOMINAL |
OVERALL WIDTH | 4.062 INCHES NOMINAL |
MATERIAL | BRASS |
SURFACE TREATMENT | ENAMEL |
MOUNTING METHOD | UNTHREADED HOLE |
STANDARD MOUNTING PATTERN DESIGNATOR | 1C 2 POINT-IN-LINE |
DISTANCE BETWEEN MOUNTING FACILITY CENTERS | 4.375 INCHES NOMINAL |
UNTHREADED MOUNTING HOLE DIAMETER | 0.344 INCHES NOMINAL |
JACK CONTACT ARRANGEMENT DESIGNATOR | J2-1A |
JACK QUANTITY | 1 |
HAZARDOUS LOCATIONS/ENVIRONMENTAL PROTECTION | SUBMERSIBLE-NEMA TYPE 6 |
FEATURES PROVIDED | COVER |
Restrictions/Controls & Freight Information | NSN 5935-00-552-6791
Category | Code | Description |
---|---|---|
Shelf-Life Code: | 0 | Nondeteriorative |
Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
Controlled Inventory Item Code: | U | UNCLASSIFIED |
Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
Precious Metals Indicator Code: | U | Precious metal type is unknown |
Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
Category | Code | Description |
---|---|---|
NMF Description | 063160 | SWITCH BOXES/ELEC ENCLOSURES |
Less than car load rating | ||
Less than truck load rating | W | Rating Variable |
Water commodity Code | 658 | unknown |
Originating Activity Code | XX | |
Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
Air Special Handling | Z | No special handling required. |
Special Handling Code | 9 | unknonwn |
HAZMAT | ||
Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5935-00-552-6791
Category | Code | Description |
---|---|---|
Materiel Category and Inventory Manager | Q | Electronics Materiel (DLA/GSA Items) |
Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
Specific Group/Generic Code | 0 | Medical Materiel |
Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
Agency | DA | Department of the Army |
Service Organization | A | U.S. Army |
Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
Controlled Item Code | U | UNCLASSIFIED |
Shelf Life Code | 0 | Nondeteriorative |
Purchasing | QTY UOM |
1 EA : Each |
Category | Code | Description |
---|---|---|
Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
Materiel Management Aggregation Code | EH | SX:ELECTRONIC COMPONENTS |
Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
Price Validation | V | The current standard price has been validated.
|
Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
Agency | DF | Department of the Air Force |
Service Organization | F | U.S. Air Force |
Reparability | N | Stock Fund (except Munitions) |
Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
Controlled Item Code | U | UNCLASSIFIED |
Shelf Life Code | 0 | Nondeteriorative |
Purchasing | QTY UOM |
1 EA : Each |
Category | Code | Description |
---|---|---|
Stores Account Code | 1 | Marine Corps Stock Fund Account Item. |
Combat Essentiality Code | 5 | Critical Repair Part to a Combat Essential End Item. Those parts or components whose failure in a combat essential end item will render the end item inoperative or reduce its effectiveness below the minimum acceptable level of efficiency. |
Materiel Management Code | B | All CommoditiesDefense Logistics Agency, (DLA,) |
Echelon Management Code | 2 | ICP/DSSC Marine Corps-managed Recoverability Code D items and Defense Logistics Agency (DLA)/TACOM/GSA) items which the integrated manager has not decontrolled. |
Operational Test Code | 0 | Items of supply which when properly packaged and placed in storage, do not require the performance of special procedures while in storage, nor prior to issue, and for which it has been determined that existing Care in Stores quality control procedures are adequate. |
Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
Agency | DM | U.S. Marine Corps |
Service Organization | M | U.S. Marine Corps |
Reparability | O | Reparable item. When uneconomically reparable, condemn and dispose of at organization level. |
Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
Controlled Item Code | U | UNCLASSIFIED |
Shelf Life Code | 0 | Nondeteriorative |
Purchasing | QTY UOM |
1 EA : Each |
Category | Code | Description |
---|---|---|
Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
Agency | DN | Department of the Navy |
Service Organization | N | U.S. Navy |
Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
Controlled Item Code | U | UNCLASSIFIED |
Shelf Life Code | 0 | Nondeteriorative |
Purchasing | QTY UOM |
1 EA : Each |
