NSN 5935-00-543-0961 ASC1560712, Z00.N7075341003, Z00N7075341003
Product Details | ELECTRICAL RECEPTACLE CONNECTOR BODY
5935-00-543-0961 The main or principal part of a CONNECTOR, RECEPTACLE, ELECTRICAL which includes insert(s) designed to accommodate but does not include removable contacts. It may have a hood or shell, a jackscrew and jacksocket, or other means for polarizing and aligning. It is designed to be mounted on a bulkhead, chassis, panel, wall, or the like. Excludes CONNECTOR BODY, MODULAR RECEPTACLE, ELECTRICAL. For items without inserts, see SHELL, ELECTRICAL CONNECTOR.
Part Alternates: ASC1560712, Z00.N7075341003, Z00N7075341003, 59F1780, 59F1780 MOLEX, 59F1780MOLEX, 03061032, 03-06-1032, 13233536-7, 16253R1, 1625-3R1, 3061032, 3-06-1032, 3466064, 346606-4, 401647, 5935-00-543-0961, 00-543-0961, 5935005430961, 005430961, 132335367
Electrical and Electronic Equipment Components | Connectors, Electrical
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 02 OCT 1974 | 00-543-0961 | 61925 ( CONNECTOR BODY, RECEPTACLE, ELECTRICAL ) |
Drawings & Photos | NSN 5935-00-543-0961
Demand History | NSN 5935-00-543-0961
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5935-00-543-0961 | 2012-06-171 | 1000 | DIBBS |
| 03061032 | 2011-07-188 | 6 | Sri Lanka |
| 5935-00-543-0961 | 2008-11-316 | 358 | DIBBS |
| 5935-00-543-0961 | 2008-10-301 | 358 | DIBBS |
| 5935-00-543-0961 | 2008-08-218 | 358 | DIBBS |
| 5935-00-543-0961 | 2008-06-164 | 358 | DIBBS |
Cross Reference | NSN 5935-00-543-0961
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 03-06-1032 | 27264 | MOLEX INCORPORATED DBA USE CAGE CODE 1UX99 FOR |
| 03-06-1032 | 92219 | TATTNALL COUNTY OF DBA TATTNALL COUNTY SHERIFFS OFFICE |
| 03-06-1032 | F5973 | RICHCO FRANCE |
| 13233536-7 | F6151 | SAFRAN |
| 13233536-7 | FAQ15 | SAGEM DEFENSE SECURITE - GROUPESAFRAN |
| 1625-3R1 | 27264 | MOLEX INCORPORATED DBA USE CAGE CODE 1UX99 FOR |
| 3-06-1032 | 27264 | MOLEX INCORPORATED DBA USE CAGE CODE 1UX99 FOR |
| 346606-4 | 61423 | KIDDE TECHNOLOGIES INC DIV KIDDE AEROSPACE AND DEFENSE |
| 401647 | 64959 | AMERICAN TELEPHONE AND TELEGRAPH CO |
| 59F1780 | 02929 | NEWARK ELECTRONICS CORPORATION DBA NEWARK |
| 59F1780 MOLEX | 02929 | NEWARK ELECTRONICS CORPORATION DBA NEWARK |
| ASC1560712 | Z4779 | ASC PTY LTD |
| Z00.N7075341003 | F0086 | SOCATA |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5935-00-543-0961
Related Products | NSN 5935-00-543-0961
Technical Data | NSN 5935-00-543-0961
| Characteristic | Specifications |
|---|---|
| BODY STYLE | 69G RECTANGULAR SHAPE |
| OVERALL LENGTH | 0.485 INCHES NOMINAL |
| OVERALL HEIGHT | 0.781 INCHES NOMINAL |
| OVERALL WIDTH | 0.180 INCHES NOMINAL |
| CONNECTOR LOCKING METHOD | FRICTION |
| POLARIZATION METHOD | MATING END |
| MATING END QUANTITY | 1 |
| CONTACT POSITION ARRANGEMENT STYLE | ADGV 3 SINGLE MATING END |
| INSERT MATERIAL | PLASTIC POLYAMIDE SINGLE MATING END |
| MISSING CONTACT TYPE AND QUANTITY | 3 ROUND SOCKET SINGLE MATING END SINGLE CONTACT GROUPING SINGLE ACCOMMODATED CONTACT TYPE |
| SPECIAL FEATURES | TAB MOUNTED |
| MANUFACTURERS CODE | 61423 |
| MFR SOURCE CONTROLLING REFERENCE | 346606-4 |
