NSN 5930-00-258-5657 SPEC 12452, SPEC12452, SYM791.1
Product Details | BOX SWITCH
5930-00-258-5657 A switch designed with its actuator extending from the box which incloses the circuit elements. The door or cover of the box is designed so that it may be readily opened or removed, thus providing relatively easy access to the circuit elements. The item is commonly designated as a safety switch or entrance switch. May be fusible and may have interlocking device.
Part Alternates: SPEC 12452, SPEC12452, SYM791.1, SYM7911, SYM791P1, SYMBOL 791.1, SYMBOL7911, 12452, 791.1, 7911, 9000S620274304TYPEA53A, 9000S6202-74304TYPEA53A, 5930-00-258-5657, 00-258-5657, 5930002585657, 002585657
Electrical and Electronic Equipment Components | Switches
Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
---|---|---|---|
59 | 01 JAN 1963 | 00-258-5657 | 02636 ( SWITCH, BOX ) |
Demand History | NSN 5930-00-258-5657
Part Number | Request Date | QTY | Origin |
---|---|---|---|
5930-00-258-5657 | 2025-01-29 | 8 | United States |
12452 | 2024-10-275 | 53 | DIBBS |
SPEC 12452 | 2024-10-275 | 53 | DIBBS |
SYM791.1 | 2024-10-275 | 53 | DIBBS |
SYM791P1 | 2024-10-275 | 53 | DIBBS |
12452 | 2024-07-198 | 53 | DIBBS |
SPEC 12452 | 2024-07-198 | 53 | DIBBS |
SYM791.1 | 2024-07-198 | 53 | DIBBS |
SYM791P1 | 2024-07-198 | 53 | DIBBS |
12452 | 2024-03-65 | 97 | DIBBS |
SPEC 12452 | 2024-03-65 | 97 | DIBBS |
SYM791.1 | 2024-03-65 | 97 | DIBBS |
SYM791P1 | 2024-03-65 | 97 | DIBBS |
12452 | 2024-02-36 | 44 | DIBBS |
SPEC 12452 | 2024-02-36 | 44 | DIBBS |
SYM791.1 | 2024-02-36 | 44 | DIBBS |
SYM791P1 | 2024-02-36 | 44 | DIBBS |
12452 | 2024-01-25 | 44 | DIBBS |
SPEC 12452 | 2024-01-25 | 44 | DIBBS |
SYM791.1 | 2024-01-25 | 44 | DIBBS |
SYM791P1 | 2024-01-25 | 44 | DIBBS |
12452 | 2023-11-320 | 42 | DIBBS |
SPEC 12452 | 2023-11-320 | 42 | DIBBS |
SYM791.1 | 2023-11-320 | 42 | DIBBS |
SYM791P1 | 2023-11-320 | 42 | DIBBS |
5930-00-258-5657 | 2023-04-113 | 1 | United States |
12452 | 2022-11-334 | 54 | DIBBS |
SPEC 12452 | 2022-11-334 | 54 | DIBBS |
SYM791.1 | 2022-11-334 | 54 | DIBBS |
SYM791P1 | 2022-11-334 | 54 | DIBBS |
12452 | 2022-09-268 | 102 | DIBBS |
SPEC 12452 | 2022-09-268 | 102 | DIBBS |
SYM791.1 | 2022-09-268 | 102 | DIBBS |
SYM791P1 | 2022-09-268 | 102 | DIBBS |
12452 | 2022-01-26 | 63 | DIBBS |
SPEC 12452 | 2022-01-26 | 63 | DIBBS |
SYM791.1 | 2022-01-26 | 63 | DIBBS |
SYM791P1 | 2022-01-26 | 63 | DIBBS |
12452 | 2021-02-47 | 92 | DIBBS |
SPEC 12452 | 2021-02-47 | 92 | DIBBS |
SYM791.1 | 2021-02-47 | 92 | DIBBS |
SYM791P1 | 2021-02-47 | 92 | DIBBS |
12452 | 2021-01-31 | 92 | DIBBS |
SPEC 12452 | 2021-01-31 | 92 | DIBBS |
SYM791.1 | 2021-01-31 | 92 | DIBBS |
SYM791P1 | 2021-01-31 | 92 | DIBBS |
12452 | 2020-02-44 | 72 | DIBBS |
SPEC 12452 | 2020-02-44 | 72 | DIBBS |
SYM791.1 | 2020-02-44 | 72 | DIBBS |
SYM791P1 | 2020-02-44 | 72 | DIBBS |
12452 | 2020-01-30 | 26 | DIBBS |
SPEC 12452 | 2020-01-30 | 26 | DIBBS |
SYM791.1 | 2020-01-30 | 26 | DIBBS |
SYM791P1 | 2020-01-30 | 26 | DIBBS |
12452 | 2019-05-136 | 13 | DIBBS |
SPEC 12452 | 2019-05-136 | 13 | DIBBS |
SYM791.1 | 2019-05-136 | 13 | DIBBS |
SYM791P1 | 2019-05-136 | 13 | DIBBS |
12452 | 2019-04-105 | 9 | DIBBS |
SPEC 12452 | 2019-04-105 | 9 | DIBBS |
SYM791.1 | 2019-04-105 | 9 | DIBBS |
SYM791P1 | 2019-04-105 | 9 | DIBBS |
12452 | 2019-04-94 | 9 | DIBBS |
SPEC 12452 | 2019-04-94 | 9 | DIBBS |
SYM791.1 | 2019-04-94 | 9 | DIBBS |
SYM791P1 | 2019-04-94 | 9 | DIBBS |
5930-00-258-5657 | 2018-02-39 | 1 | US |
5930-00-258-5657 | 2014-03-70 | 51 | DIBBS |
5930-00-258-5657 | 2014-01-29 | 33 | DIBBS |
5930-00-258-5657 | 2014-01-27 | 1 | DIBBS-RFPs |
5930-00-258-5657 | 2013-12-352 | 29 | DIBBS |
5930-00-258-5657 | 2013-10-275 | 36 | DIBBS |
5930-00-258-5657 | 2012-08-230 | 34 | DIBBS |
5930-00-258-5657 | 2012-07-185 | 30 | DIBBS |
5930-00-258-5657 | 2012-03-90 | 24 | DIBBS |
5930-00-258-5657 | 2012-03-62 | 56 | DIBBS |
5930-00-258-5657 | 2011-12-362 | 33 | DIBBS |
5930-00-258-5657 | 2011-12-339 | 38 | DIBBS |
5930-00-258-5657 | 2011-09-252 | 124 | DIBBS |
5930-00-258-5657 | 2009-04-106 | 32 | DIBBS |
5930-00-258-5657 | 2009-03-89 | 17 | DIBBS |
5930-00-258-5657 | 2009-02-49 | 33 | DIBBS |
5930-00-258-5657 | 2008-08-243 | 31 | DIBBS |
5930-00-258-5657 | 2007-12-345 | 60 | DIBBS |
5930-00-258-5657 | 2007-11-330 | 60 | DIBBS |
5930-00-258-5657 | 2007-10-278 | 34 | DIBBS |
5930-00-258-5657 | 2007-09-269 | 27 | DIBBS |
5930-00-258-5657 | 2007-09-253 | 11 | DIBBS |
5930-00-258-5657 | 2007-06-172 | 17 | DIBBS |
5930-00-258-5657 | 2007-05-130 | 27 | DIBBS |
5930-00-258-5657 | 2007-02-36 | 23 | DIBBS |
Cross Reference | NSN 5930-00-258-5657
Part Number | Cage Code | Manufacturer |
---|---|---|
12452 | 28057 | SHALLCO, INC. |
791.1 | 28003 | WINCHESTER INDUSTRIES INC |
9000S6202-74304TYPEA53A | 28057 | SHALLCO, INC. |
9000S6202-74304TYPEA53A | 80064 | NAVAL SHIP SYSTEMS COMMAND |
9000S6202-74304TYPEA53A | 88829 | TABET MANUFACTURING COMPANY, INC. |
SPEC 12452 | 28057 | SHALLCO, INC. |
SYM791.1 | 44291 | U.S. PIONEER, L.L.C. DBA U.S. PIONEER |
SYM791.1 | 58475 | WESTWOOD CORPORATION DBA NMP DIVISION |
SYM791P1 | 86796 | ROFLAN ASSOCIATES INC |
SYMBOL 791.1 | 80064 | NAVAL SHIP SYSTEMS COMMAND |
Request a Quote
What Our Customers Say
Compare
NSNs for Compare ( up to 4 ): Add 5930-00-258-5657
Related Products | NSN 5930-00-258-5657
Technical Data | NSN 5930-00-258-5657
Characteristic | Specifications |
---|---|
NONPILE-UP CONTACT ARRANGEMENT | 6 POLE, SINGLE THROW, NORMALLY OPEN, DOUBLE MAKE, MOMENTARY ACTION SINGLE SWITCH UNIT |
MAXIMUM VOLTAGE RATING IN VOLTS | 120.0 AC AND 120.0 DC |
CONTACT LOAD CURRENT RATING AT MAXIMUM RATED VOLTAGE | 10.000 AMPERES RESISTIVE DC AND 25.000 AMPERES RESISTIVE AC |
BODY STYLE | 3B WITH SIDE OPERATOR |
CENTER TO CENTER DISTANCE BETWEEN MOUNTING FACILITIES PARALLEL TO LENGTH | 6.125 INCHES NOMINAL |
CENTER TO CENTER DISTANCE BETWEEN MOUNTING FACILITIES PARALLEL TO WIDTH | 4.750 INCHES NOMINAL |
BODY LENGTH | 6.000 INCHES NOMINAL |
BODY WIDTH | 4.950 INCHES NOMINAL |
BODY HEIGHT | 5.000 INCHES NOMINAL |
ACTUATOR STYLE | 51 ROLLER ARM |
ACTUATOR LENGTH | 3.000 INCHES NOMINAL |
ACTUATOR HEIGHT | 1.750 INCHES NOMINAL |
ACTUATOR ROLLER DIAMETER | 0.500 INCHES NOMINAL |
ACTUATOR ROLLER WIDTH | 0.125 INCHES NOMINAL |
TERMINAL TYPE AND QUANTITY | 16 SCREW |
MOUNTING METHOD | BRACKET AND UNTHREADED HOLE |
UNTHREADED MOUNTING HOLE DIAMETER | 0.375 INCHES NOMINAL |
Restrictions/Controls & Freight Information | NSN 5930-00-258-5657
Category | Code | Description |
---|---|---|
Shelf-Life Code: | 0 | Nondeteriorative |
Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
Controlled Inventory Item Code: | U | UNCLASSIFIED |
Precious Metals Indicator Code: | U | Precious metal type is unknown |
Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
Category | Code | Description |
---|---|---|
NMF Description | 063160 | SWITCH BOXES/ELEC ENCLOSURES |
Less than car load rating | ||
Less than truck load rating | W | Rating Variable |
Water commodity Code | 72D | unknown |
Originating Activity Code | XX | |
Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
Air Special Handling | Z | No special handling required. |
Special Handling Code | 9 | unknonwn |
HAZMAT | ||
Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5930-00-258-5657
Category | Code | Description |
---|---|---|
Materiel Category and Inventory Manager | Q | Electronics Materiel (DLA/GSA Items) |
Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
Specific Group/Generic Code | 0 | Medical Materiel |
Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
Agency | DA | Department of the Army |
Service Organization | A | U.S. Army |
Reparability | A | Item requires special handling or condemnation procedures for specific reasons, such as precious metal content, high dollar value, critical material, or hazardous materiel. Refer to appropriate manuals or directives for specific instructions. |
Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
Controlled Item Code | U | UNCLASSIFIED |
Shelf Life Code | 0 | Nondeteriorative |
Purchasing | QTY UOM |
1 EA : Each |
Category | Code | Description |
---|---|---|
Cognizance Codes | 3B | Navy-owned stocks of field level repairable DLA material Naval Inventory Control Point, Mechanicsburg |
Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
Agency | DN | Department of the Navy |
Service Organization | N | U.S. Navy |
Reparability | D | Field Level Reparables |
Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
Controlled Item Code | U | UNCLASSIFIED |
Shelf Life Code | 0 | Nondeteriorative |
Purchasing | QTY UOM |
1 EA : Each |
