NSN 5930-00-237-7726 S285146G1, S28-5146G1, W285146
Product Details | INTERLOCK SWITCH
5930-00-237-7726 An item which completes or interrupts the connections in one or more electrical circuits. Its electrical elements consist of separate parts designed to be mounted respectively on a frame and a door, drawer, or cover, It acts as a safety device to open a circuit when the door or drawer is opened or the cover removed. It does not include devices of which a complete switch with an actuator is one of the parts; for such devices, use SWITCH (as modified). Excludes SWITCH, MERCURY; and SWITCH, REED.
Part Alternates: S285146G1, S28-5146G1, W285146, W28-5146 , 285146G1, 28-5146G1, 4600, 491009, 5930-00-237-7726, 00-237-7726, 5930002377726, 002377726
Electrical and Electronic Equipment Components | Switches
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1963 | 00-237-7726 | 00403 ( SWITCH, INTERLOCK ) |
Drawings & Photos | NSN 5930-00-237-7726
Demand History | NSN 5930-00-237-7726
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 4600 | 2011-03-61 | 1 | ID |
Cross Reference | NSN 5930-00-237-7726
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 28-5146G1 | 3B150 | RAYTHEON TECHNICAL SERVICES COMPANY LLC |
| 28-5146G1 | 49956 | RAYTHEON COMPANY DBA RAYTHEON |
| 4600 | 71183 | BRYANT ELECTRIC |
| 4600 | 79500 | WESTINGHOUSE ELECTRIC CORP |
| 491009 | 99993 | DEPARTMENT OF THE NAVY |
| S28-5146G1 | 3B150 | RAYTHEON TECHNICAL SERVICES COMPANY LLC |
| S28-5146G1 | 49956 | RAYTHEON COMPANY DBA RAYTHEON |
| W28-5146 | 3B150 | RAYTHEON TECHNICAL SERVICES COMPANY LLC |
| W28-5146 | 49956 | RAYTHEON COMPANY DBA RAYTHEON |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5930-00-237-7726
Technical Data | NSN 5930-00-237-7726
| Characteristic | Specifications |
|---|---|
| NONPILE-UP CONTACT ARRANGEMENT | 1 POLE, SINGLE THROW, BOTH POSITIONS MAINTAINED SINGLE SWITCH UNIT |
| MAXIMUM VOLTAGE RATING IN VOLTS | 250.0 AC |
| CONTACT LOAD CURRENT RATING AT MAXIMUM RATED VOLTAGE | 5.000 AMPERES RESISTIVE AC |
| TERMINAL TYPE AND QUANTITY | 2 SCREW |
Restrictions/Controls & Freight Information | NSN 5930-00-237-7726
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061300 | CIRCUIT BREAKER/SWITCH NOI |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 658 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5930-00-237-7726
Air Force| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Materiel Management Aggregation Code | EH | SX:ELECTRONIC COMPONENTS |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
