Product Details | OVERVOLTAGE ABSORBER

5920-01-534-6494 An item specifically designed to absorb and consume surges of voltage such as that resulting across contacts when breaking a circuit having an inductive load or a burst of static across a telephone receiver. It is connected in parallel with the item it is protecting. It may be made up of metallic rectifier cells or semiconductor devices connected back-to-back which may or may not be shunted by a capacitor. It may also be a single rectifier cell or semiconductor device shunted by a capacitor. Excludes metallic rectifiers which are rated for rectifying capabilities and all single unit semiconductor devices not shunted by a capacitor. For items perfoming this function by use of voltage sensitive resistors, see RESISTOR, VOLTAGE SENSITIVE. See also CUTOUT DISK, PROTECTIVE.

Part Alternates: ITD80A480NNUSNF, ITD80A-480NN-USN-F, 5920-01-534-6494, 01-534-6494, 5920015346494, 015346494

Electrical and Electronic Equipment Components | Fuses, Arrestors, Absorbers, and Protectors

Supply Group (FSG) NSN Assign. NIIN
59 28 OCT 2005 01-534-6494

Drawings & Photos | NSN 5920-01-534-6494


Demand History | NSN 5920-01-534-6494

Part Number Request Date QTY Origin
ITD80A480NNUSNF 2024-09-268 1 US
ITD80A-480NN-USN-F 2024-08-235 14 DIBBS
ITD80A-480NN-USN-F 2024-02-53 14 DIBBS
ITD80A-480NN-USN-F 2023-06-172 19 DIBBS
ITD80A-480NN-USN-F 2023-06-171 19 DIBBS
ITD80A-480NN-USN-F 2023-06-166 19 DIBBS
ITD80A-480NN-USN-F 2023-06-165 19 DIBBS
ITD80A-480NN-USN-F 2023-06-163 19 DIBBS
ITD80A-480NN-USN-F 2023-06-160 19 DIBBS
ITD80A-480NN-USN-F 2023-06-158 19 DIBBS
ITD80A-480NN-USN-F 2023-06-156 19 DIBBS
ITD80A-480NN-USN-F 2023-06-152 19 DIBBS
ITD80A-480NN-USN-F 2023-05-121 19 DIBBS
ITD80A-480NN-USN-F 2023-04-115 19 DIBBS
ITD80A-480NN-USN-F 2023-04-114 19 DIBBS
ITD80A-480NN-USN-F 2023-04-111 19 DIBBS
ITD80A-480NN-USN-F 2023-04-110 19 DIBBS
ITD80A-480NN-USN-F 2023-04-107 19 DIBBS
ITD80A-480NN-USN-F 2023-04-96 19 DIBBS
ITD80A-480NN-USN-F 2022-03-90 11 DIBBS
5920-01-534-6494 2022-02-59 1 US
ITD80A-480NN-USN-F 2021-10-280 6 DIBBS
ITD80A-480NN-USN-F 2021-07-210 5 DIBBS
5920-01-534-6494 2017-02-33 6 DIBBS
5920-01-534-6494 2016-06-154 3 DIBBS
5920-01-534-6494 2016-01-12 1 DIBBS
5920-01-534-6494 2015-07-211 25 US
5920-01-534-6494 2008-10-284 40 DIBBS
5920-01-534-6494 2007-07-188 1 DIBBS
5920-01-534-6494 2007-03-68 2 DIBBS

Cross Reference | NSN 5920-01-534-6494

Part Number Cage Code Manufacturer
ITD80A-480NN-USN-F 1PDW4 SURGE SUPPRESSION INCORPORATED DBA ITD OF DESTIN

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 5920-01-534-6494

Technical Data | NSN 5920-01-534-6494

Characteristic Specifications
OVERALL LENGTH 11.500 INCHES NOMINAL
OVERALL WIDTH 6.580 INCHES NOMINAL
OVERALL HEIGHT 6.290 INCHES NOMINAL
CURRENT TYPE AC
VOLTAGE IN VOLTS 480.0
SPECIAL FEATURES ITEM IS SINGLE PORT, CLASS B ,TYPE 1, PARALLEL CONNECTED TRANSIENT VOLTAGE SURGE SUPPRESSORUTILIZING HYBRID CIRCUITRY WITH 80 KA PER MODE AND 240 KA PER PHASE PEAK SURGECURRENT
III USAGE DESIGN TO PROTECT LOADS FED FROM DISTRIBUTION PANELS, BRANCH PANELS AND OR CRITICAL LOAD CENTERS ABOARD SHIP OR SHORE BASED POWER DISTRIBUTION SYSTEMS.

Restrictions/Controls & Freight Information | NSN 5920-01-534-6494

Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodePThere is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:UUNCLASSIFIED
Electro-static Discharge Susceptible:ANo known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
NMF Description 062380 LIGHTNING ARRESTERS/PARTS NOI
Less than car load rating
Less than truck load rating P 77.5
Water commodity Code 72D unknown
Originating Activity Code TX Defense Supply Center Columbus
Columbus, OH 43218
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity H Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc.
Air Special Handling Z No special handling required.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable

Management | NSN 5920-01-534-6494

Category Code Description
Cognizance Codes9BNavy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDNDepartment of the Navy
Service OrganizationNU.S. Navy
Acquisition Advice CodesJNOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
