NSN 5915-01-305-3006 DLC-28/2, DLC282, 20022395801
Product Details | IMPEDANCE MATCHING NETWORK
5915-01-305-3006 A grouping of two or more different discrete items, such as resistors, coils, and capacitors, electrically connected and used as a unit to couple two or more circuits in such a manner that the impedance of each circuit will be equal to the impedance into which it hooks. For items fabricated by monolithic and/or thin film techniques, see MICROCIRCUIT (as modified). See also ATTENUATOR (as modified); and TRANSFORMER (as modified). Excludes RESISTOR SET, MATCHED.
Part Alternates: DLC-28/2, DLC282, 20022395801, 200223958-01, 43940, 5012280002, 5012280-002, 79P006000, 79P0060-00 , 9050102, 90-50102, 9050202, 90-50202 , 5915-01-305-3006, 01-305-3006, 5915013053006, 013053006
Electrical and Electronic Equipment Components | Filters and Networks
