NSN 5915-00-103-0608 5860241, 586024-1, 00-103-0608
Product Details | PULSE FORMING NETWORK
5915-00-103-0608 A grouping of two or more different discrete items, such as resistors, coils, and capacitors, electrically connected and used to shape the leading and/or trailing edge of a pulse. For items fabricated by monolithic and/or thin film techniques, see MICROCIRCUIT (as modified). See also ATTENUATOR (as modified); FILTER (as modified); and TRANSFORMER (as modified).
Part Alternates: 5860241, 586024-1, 5915-00-103-0608, 00-103-0608, 5915001030608, 001030608
Electrical and Electronic Equipment Components | Filters and Networks
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 05 JUN 1968 | 00-103-0608 | 60769 ( NETWORK, PULSE FORMING ) |
Cross Reference | NSN 5915-00-103-0608
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 586024-1 | 96214 | RAYTHEON COMPANY DBA RAYTHEON |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5915-00-103-0608
Technical Data | NSN 5915-00-103-0608
| Characteristic | Specifications |
|---|---|
| SPECIAL FEATURES | IMPEDENCE 40.0 OHMS; PEAK VOLTAGE 700.0 VDC; OPERATING TEMP RANGE MINUS 54.0 DEG C TO PLUS 85.0 DEG C; 5 TURRET TERMINALS; 3.97 IN. L; 3.92 IN. W; 3.25 IN. H |
| MANUFACTURERS CODE | 96214 |
| DESIGN CONTROL REFERENCE | 586024-1 |
Restrictions/Controls & Freight Information | NSN 5915-00-103-0608
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061400 | CONDENSERS/PARTS NOI/CAPACITORS |
| Less than car load rating | P | 77.5 |
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | KE | Naval ICP Philadelphia, PA 19111 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | Z | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5915-00-103-0608
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
