Product Details | PULSE FORMING NETWORK

5915-00-333-9907 A grouping of two or more different discrete items, such as resistors, coils, and capacitors, electrically connected and used to shape the leading and/or trailing edge of a pulse. For items fabricated by monolithic and/or thin film techniques, see MICROCIRCUIT (as modified). See also ATTENUATOR (as modified); FILTER (as modified); and TRANSFORMER (as modified).

Part Alternates: NB672472A, NB672-472A, PSP1A, PSP-1A, ZN1505, 07M102 , 679729, 7M102, 831006, 8310062, 831006-2, 9011809, 5915-00-333-9907, 00-333-9907, 5915003339907, 003339907

Electrical and Electronic Equipment Components | Filters and Networks

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
59	01 JAN 1963	00-333-9907	60769 ( NETWORK, PULSE FORMING )

Drawings & Photos | NSN 5915-00-333-9907

Part Number	Request Date	QTY	Origin
5915-00-333-9907	2018-10-285	10	DIBBS
5915-00-333-9907	2018-10-274	10	DIBBS
5915003339907	2012-01-30	5	AE
5915-00-333-9907	2011-01-12	10	DIBBS
5915-00-333-9907	2010-01-07	8	DIBBS
5915-00-333-9907	2009-07-188	16	DIBBS
5915-00-333-9907	2009-06-180	16	DIBBS
5915-00-333-9907	2008-04-95	1	United States
5915-00-333-9907	2008-01-11	3	Canada
5915-00-333-9907	2007-07-195	27	DIBBS

Cross Reference | NSN 5915-00-333-9907

Part Number	Cage Code	Manufacturer
07M102	13058	SORA POWER INC.
679729	56232	LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN
7M102	13058	SORA POWER INC.
831006	00779	TYCO ELECTRONICS CORPORATION
831006-2	00779	TYCO ELECTRONICS CORPORATION
9011809	97151	AIR FORCE LOGISTICS COMMAND 88 0SS OSE
NB672-472A	58364	BYCAP INC
PSP-1A	21966	TDL, INC DBA T D L
ZN1505	13619	EMS DEVELOPMENT CORPORATION
