Product Details | HIGH PASS FILTER
5915-00-103-0289 An item designed to pass all frequencies above a specified frequency. Excludes a single inductance, a single capacitance, or a single resistance. See COIL (as modified); REACTOR; CAPACITOR (as modified); and RESISTOR (as modified).
Part Alternates: G624040, GS67194, 5915-00-103-0289, 00-103-0289, 5915001030289, 001030289
Electrical and Electronic Equipment Components | Filters and Networks
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 12 JUN 1968 | 00-103-0289 | 13910 ( FILTER, HIGH PASS ) |
Drawings & Photos | NSN 5915-00-103-0289
Cross Reference | NSN 5915-00-103-0289
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| G624040 | 06KW9 | LUCENT TECHNOLOGIES INC DBA FEDERAL MARKETING GROUP |
| G624040 | 3B4M0 | LUCENT TECHNOLOGIES INC CORPORATE HEADQUARTERS |
| G624040 | 64959 | AMERICAN TELEPHONE AND TELEGRAPH CO |
| GS67194 | 06KW9 | LUCENT TECHNOLOGIES INC DBA FEDERAL MARKETING GROUP |
| GS67194 | 3B4M0 | LUCENT TECHNOLOGIES INC CORPORATE HEADQUARTERS |
| GS67194 | 64959 | AMERICAN TELEPHONE AND TELEGRAPH CO |
