NSN 5910-00-441-7749 CV31B250, MIL-C-81/4, MILC814
Product Details | CERAMIC DIELECTRIC VARIABLE CAPACITOR
5910-00-441-7749 A capacitor whose capacitance value is controlled by a mechanical means which effects a continuous variation of its capacitance. It includes items consisting of two or more variable capacitors which are inseparable.
Part Alternates: CV31B250, MIL-C-81/4, MILC814, F171, 16763335002, 16763335-002, 216990122836, 216-990122-836, 8290100004, 829010-0004, 9170004040, 917-0004-040, 281-0160-00, 3005322, 3005-322, 5358294, 535829-4, 538011725PF, 538-011-7-25PF, 538011B2P093R, 538-011B2P093R, 538011B725, 538-011B7-25, 538011C0P093R, 538-011C0P093R, 538011E2P093R, 538-011E2P0-93R, 538054B7025, 538054B7-0-25, 5910-00-441-7749, 00-441-7749, 5910004417749, 004417749, 281016000
Electrical and Electronic Equipment Components | Capacitors
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 10 DEC 1969 | 00-441-7749 | 00721 ( CAPACITOR, VARIABLE, CERAMIC DIELECTRIC ) |
Drawings & Photos | NSN 5910-00-441-7749
Demand History | NSN 5910-00-441-7749
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| F171 | 2019-06-175 | 1 | US |
| 5910-00-441-7749 | 2017-04-108 | 1 | DIBBS-RFPs |
Cross Reference | NSN 5910-00-441-7749
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 16763335-002 | 06KW9 | LUCENT TECHNOLOGIES INC DBA FEDERAL MARKETING GROUP |
| 216-990122-836 | 38753 | CMC ELECTRONICS INC |
| 281-0160-00 | 80378 | TRIUMPH AEROSTRUCTURES, LLC DBA TRIUMPH AEROSTRUCTURES - VOUGHT |
| 3005-322 | 05869 | RAYTHEON COMPANY DBA RAYTHEON |
| 535829-4 | 96214 | RAYTHEON COMPANY DBA RAYTHEON |
| 538-011-7-25PF | 72982 | ERIE SPECIALTY PRODUCTS INC |
| 538-011B2P093R | 72982 | ERIE SPECIALTY PRODUCTS INC |
| 538-011B7-25 | 72982 | ERIE SPECIALTY PRODUCTS INC |
| 538-011C0P093R | 72982 | ERIE SPECIALTY PRODUCTS INC |
| 538-011E2P0-93R | 72982 | ERIE SPECIALTY PRODUCTS INC |
| 538054B7-0-25 | 59660 | TUSONIX, INC. |
| 538054B7-0-25 | 72982 | ERIE SPECIALTY PRODUCTS INC |
| 829010-0004 | 65597 | THALES DEFENSE & SECURITY, INC. |
| 917-0004-040 | 13499 | ROCKWELL COLLINS, INC. DBA GOVERNMENT SYSTEMS |
| 917-0004-040 | 95105 | ROCKWELL COLLINS, INC. DIV GOVERNMENT SYSTEMS - DALLAS |
| CV31B250 | 00721 | WARNER AND SWASEY RESEARCH CORP |
| CV31B250 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| F171 | 57655 | NAUTEL MAINE INC. |
| MIL-C-81/4 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5910-00-441-7749
Related Products | NSN 5910-00-441-7749
Technical Data | NSN 5910-00-441-7749
| Characteristic | Specifications |
|---|---|
| CAPACITANCE RANGE IN PICOFARADS | 7.0 TO 25.0 SINGLE SECTION |
| NONDERATED VOLTAGE RATING AND TYPE | 350.0 DC CONTINUOUS SINGLE SECTION |
| NONDERATED OPERATING TEMP | -55.0 DEG CELSIUS MINIMUM AND 85.0 DEG CELSIUS MAXIMUM |
| CAPACITANCE CHANGE IN PERCENT AT OPERATING TEMP FROM 25 DEG CELSIUS | -1.00 TO 3.50 MINIMUM AND -2.50 TO -0.50 MAXIMUM SINGLE SECTION |
| BODY STYLE | 52 ROTARY |
| OVERALL HEIGHT | 0.310 INCHES NOMINAL |
| OVERALL DIAMETER | 0.370 INCHES NOMINAL |
| INCLOSURE TYPE | ENCAPSULATED |
| ADJUSTMENT DEVICE DRIVE TYPE AND QUANTITY | 1 SLOTTED SCREW |
| ADJUSTMENT DEVICE TORQUE | 1.000 INCH-OUNCES MINIMUM AND 6.000 INCH-OUNCES MAXIMUM |
| TERMINAL TYPE AND QUANTITY | 2 PIN |
| CENTER TO CENTER DISTANCE BETWEEN TERMINALS PARALLEL TO DIAMETER | ANY ACCEPTABLE |
| MOUNTING FACILITY TYPE AND QUANTITY | 2 TERMINAL |
| TEST DATA DOCUMENT | 81349-MIL-C-81 SPECIFICATION |
| III CAPACITANCE DRIFT IN PICOFARADS | 0.50 SINGLE SECTION |
| III INSULATION DC RESISTANCE AT 25 DEG CELSIUS | 10.0 GIGOHMS |
| III DISSIPATION FACTOR AT 25 DEG CELSIUS IN PERCENT | 0.2 |
| MANUFACTURERS CODE | 81349 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | CV31B250 |
| MANUFACTURERS CODE | 81349 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MIL-C-81/4 |
Restrictions/Controls & Freight Information | NSN 5910-00-441-7749
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061400 | CONDENSERS/PARTS NOI/CAPACITORS |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | TX | Defense Supply Center Columbus Columbus, OH 43218 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5910-00-441-7749
Army
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | Q | Electronics Materiel (DLA/GSA Items) |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
| Specific Group/Generic Code | 0 | Medical Materiel |
| Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
| Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Materiel Management Aggregation Code | EH | SX:ELECTRONIC COMPONENTS |
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Price Validation | V | The current standard price has been validated.
|
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
