NSN 5910-00-323-9359 00-323-9359, 003239359
Product Details | PLASTIC DIELECTRIC FIXED CAPACITOR
5910-00-323-9359 A capacitor whose capacitance value cannot be adjusted or varied, having a plastic, plastic film, plasticized (plastic impregnated) paper, or any combination of plastic and paper or plastic and paper films as the dielectric material. The plastic may be one or more types of synthetic compounds such as polyesters, polyfluorides, polycabonates, and the like. It may be a single unit, or consist of two or more fixed units which cannot be separated. For items whose electrodes consist of a metallic film deposited (metallized) on the dielectric material, see CAPACITOR, FIXED, METALLIZED, PAPER-PLASTIC DIELECTRIC.
Part Alternates: 5910-00-323-9359, 00-323-9359, 5910003239359, 003239359
Electrical and Electronic Equipment Components | Capacitors
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 00-323-9359 | 00006 ( CAPACITOR, FIXED, PLASTIC DIELECTRIC ) |
Drawings & Photos | NSN 5910-00-323-9359
Cross Reference | NSN 5910-00-323-9359
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 16C43767-5704 | 53711 | NAVAL SEA SYSTEMS COMMAND |
| 191P10352S4 | 56289 | SPRAGUE ELECTRIC CO WORLD HQS |
| 195P10396S4 | 01884 | DEARBORN ELECTRONICS, INC. |
| 195P10396S4 | 56289 | SPRAGUE ELECTRIC CO WORLD HQS |
| 238990 | 36378 | RAYTHEON TECHNICAL SERVICES COMPANY |
| 432076-2 | 0UU57 | BLUE WAVE ULTRASONICS, INC. |
| 615G10396 | 84411 | AMERICAN SHIZUKI CORPORATION |
| 615G10396W2 | 84411 | AMERICAN SHIZUKI CORPORATION |
| 87C103 | 76823 | NORTHROP GRUMMAN SYSTEMS CORPORATION DIV NORTHROP GRUMMAN AEROSPACE |
| 91P10396S2 | 56289 | SPRAGUE ELECTRIC CO WORLD HQS |
| CN35A103M | 06845 | RAYTHEON COMPANY DBA RAYTHEON |
| CN35AF103K | 31349 | IVENS WM H AND SONS CO |
| CP05A1KF103K3 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| CP05EF103K | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| CPV08A1KE103K | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| CPV09A1KE103JR | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| CPV09A1KF103JR | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| CPV09A1KF103K | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| CPV09A1KF103KM | 72928 | GULTON INDUSTRIES INC GUDEMAN DIV |
| CPV09A1KF103KM | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| CPV09A1KF103KR | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| CQ05A1KF103K3 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| CQ08A1KE103K3 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| CQ09A1KF103J3 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| CQR09A1KE103J3M | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| CQR09A1KF103J3L | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| CQR09A1KF103J3P | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| CQR09A1KF103K3L | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| CQR09A1KF103K3M | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| CQR09A1KF103K3P | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| M14157-2-4029R | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| M14157-2-6049R | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| M14157-2-6050M | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| M14157-2-6050R | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| M19978-1-0591J | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| MIL-C-19978/19 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| MIL-C-19978/9 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| MILC14157-2 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| MILC19978-1 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| ND21749-001 | 65092 | SOLARTRON ELECTRONICS INC WESTON INSTRUMENTS DIV |
| PJ4S1 | 14655 | CORNELL-DUBILIER ELECTRONICS |
| PTE6S1 | 14655 | CORNELL-DUBILIER ELECTRONICS |
| PX24B13 | 56289 | SPRAGUE ELECTRIC CO WORLD HQS |
| SMB190181-2 | 80063 | US ARMY COMMUNICATIONS & ELECTRONICS MATERIEL READINESS |
| SP96P1039652 | 56209 | STAR SHADE CUTTER CO |
| ST4S1 | 14655 | CORNELL-DUBILIER ELECTRONICS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5910-00-323-9359
Related Products | NSN 5910-00-323-9359
Technical Data | NSN 5910-00-323-9359
| Characteristic | Specifications |
|---|---|
| CAPACITANCE VALUE PER SECTION | 10000.000 PICOFARADS SINGLE SECTION |
| TOLERANCE RANGE PER SECTION | -5.00 TO 5.00 PERCENT SINGLE SECTION |
| NONDERATED CONTINUOUS VOLTAGE RATING AND TYPE PER SECTION | 400.0 DC SINGLE SECTION |
| NONDERATED OPERATING TEMP | -55.0 DEG CELSIUS MINIMUM AND 125.0 DEG CELSIUS MAXIMUM |
| BODY STYLE | 26B W/O MTG FACILITIES, AXIAL TERMINALS |
| BODY DIAMETER | 0.332 INCHES NOMINAL |
| BODY LENGTH | 0.938 INCHES NOMINAL |
| SCHEMATIC DIAGRAM DESIGNATOR | 1C NO COMMON OR GROUNDED ELECTRODE(S) |
| TERMINAL TYPE AND QUANTITY | 2 UNINSULATED WIRE LEAD |
| TERMINAL LENGTH | 1.625 INCHES MINIMUM |
| TERMINAL DIAMETER | 0.025 INCHES NOMINAL |
| CASE MATERIAL | METAL |
| CASE INSULATION MATERIAL | PLASTIC |
| INSULATION RESISTANCE AT REFERENCE TEMP | 25000.0 MEGOHMS |
| DISSIPATION FACTOR AT REFERENCE TEMP IN PERCENT | 0.6000 |
| RELIABILITY INDICATOR | ESTABLISHED |
| RELIABILITY FAILURE RATE LEVEL IN PERCENT | 0.0100 |
| FEATURES PROVIDED | HERMETICALLY SEALED CASE |
| TEST DATA DOCUMENT | 81349-MIL-C-14157 SPECIFICATION |
| SPECIFICATION/STANDARD DATA | 81349-MIL-C-14157/2 GOVERNMENT SPECIFICATION |
| III TERMINAL SURFACE TREATMENT | SOLDER |
| III INTERNAL ELECTRICAL CONNECTION TYPE | EXTENDED FOIL |
| III DIELECTRIC MATERIAL | PLASTIC |
| (NON-CORE DATA) OVERALL LENGTH | 1.314 INCHES MAXIMUM |
| III INSULATION RESISTANCE AT MAXIMUM OPERATING TEMP | 20.0 MEGOHM-MICROFARADS |
| (NON-CORE DATA) OVERALL HEIGHT | 0.332 INCHES NOMINAL |
| (NON-CORE DATA) OVERALL WIDTH | 0.332 INCHES NOMINAL |
| MANUFACTURERS CODE | 81349 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MILC14157-2 |
| MANUFACTURERS CODE | 81349 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | M14157-2-4029R |
Restrictions/Controls & Freight Information | NSN 5910-00-323-9359
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
