NSN 5905-01-167-6975 12616, 23708, 7648736P013
Product Details | PRECISION NONWIRE WOUND VARIABLE RESISTOR
5905-01-167-6975 A resistor in which a sliding or rolling contact moves over an exposed area of the resistive element to change the ohmic value of the output. The finctional tolerance (linearity) of the output is equal to or less than plus or minus 1 percent on linear outputs. Specified outputs such as sine, cosine, tangent, etc., shall be considered to be precision. For items having manually postioned taps designed to be set and fixed prior to use, see RESISTOR, ADJUSTABLE. For items with step by step variation, see REHOSTAT and RESISTOR, STEP BY STEP. For tandem-mounted items designed to function together as an attenuator (and rated accordingly), see ATTENUATOR, VARIABLE. Excludes RESISTOR (1), VARIABLE, WIRE WOUND, NONPRECISION; RESISTOR (1), VARIABLE NONWIRE WOUND, NONPRECISION; and RESISTOR (1), VARIABLE, WIRE WOUND, PRECISION.
Part Alternates: 12616, 23708, 7648736P013, 7648736P13, 5905-01-167-6975, 01-167-6975, 5905011676975, 011676975
Electrical and Electronic Equipment Components | Resistors
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 03 DEC 1983 | 01-167-6975 | 37407 ( RESISTOR, VARIABLE, NONWIRE WOUND, PRECISION ) |
Drawings & Photos | NSN 5905-01-167-6975
Demand History | NSN 5905-01-167-6975
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 7648736P13 | 2023-07-192 | 1 | DIBBS |
| 12616 | 2018-08-233 | 1 | ZA |
Cross Reference | NSN 5905-01-167-6975
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 12616 | 04454 | SENSOR SYSTEMS, L.L.C. |
| 23708 | 98659 | DONEL SYSTEMS, LLC DIV DONEL SYSTEMS LLC |
| 7648736P013 | 03538 | LOCKHEED MARTIN CORPORATION DIV MST |
| 7648736P13 | 03538 | LOCKHEED MARTIN CORPORATION DIV MST |
| 7648736P13 | 06481 | NORTHROP GRUMMAN SYSTEMS CORPORATION |
| 7648736P13 | 13973 | LITTON SYSTEMS INC. DIV NAVIGATION SYSTEMS DIVISION |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5905-01-167-6975
Related Products | NSN 5905-01-167-6975
Technical Data | NSN 5905-01-167-6975
| Characteristic | Specifications |
|---|---|
| SECTION QUANTITY | 2 |
| ELECTRICAL RESISTANCE PER SECTION | 5.000 KILOHMS ALL SECTIONS |
| RESISTANCE TOLERANCE PER SECTION IN PERCENT | -10.0 TO 10.0 ALL SECTIONS |
| FUNCTION CONFORMITY PER SECTION | ALL SECTIONS INDEPENDENT LINEARITY |
| FUNCTION CHARACTERISTIC PER SECTION | ALL SECTIONS LINEAR |
| FUNCTION CONFORMITY TOLERANCE PER SECTION | -0.05 TO 0.05 1ST SECTION -0.10 TO 0.10 2ND SECTION |
| SHAFT RUNOUT | 0.001 INCHES |
| LATERAL RUNOUT | 0.002 INCHES |
| PILOT DIAMETER RUNOUT | 0.00100 INCHES |
| SHAFT RADIAL PLAY | 0.001 INCHES |
| MECHANICAL BACKLASH IN DEG ANGULAR ROTATION | 0.041 |
| SHAFT BEARING TYPE | BALL |
| SHAFT END PLAY | 0.00500 INCHES |
| MAXIMUM STARTING TORQUE | 0.70 INCH-OUNCES |
| MAXIMUM RUNNING TORQUE | 0.70 INCH-OUNCES |
| RESISTANCE TEMP CHARACTERISTIC RANGE PER SECTION IN PERCENT | -5.0 TO 5.0 -65 DEG CELSIUS ALL SECTIONS AND -4.0 TO 4.0 -15 DEG CELSIUS ALL SECTIONS AND -2.5 TO 2.5 50 DEG CELSIUS ALL SECTIONS AND -5.0 TO 5.0 75 DEG CELSIUS ALL SECTIONS AND -5.0 TO 5.0 105 DEG CELSIUS ALL SECTIONS AND -5.0 TO 5.0 125 DEG CELSIUS ALL SECTIONS |
| POWER DISSIPATION RATING PER SECTION IN WATTS | 2.0 FREE AIR ALL SECTIONS |
| AMBIENT TEMP IN DEG CELSIUS PER SECTION AT FULL RATED POWER | 40.0 ALL SECTIONS |
| AMBIENT TEMP IN DEG CELSIUS PER SECTION AT ZERO PERCENT RATED POWER | 125.0 ALL SECTIONS |
| FIXED TAP QUANTITY PER SECTION | 1 1ST SECTION |
| TAP LOCATION FROM CCW TERMINAL PER SECTION IN OHMS | 2500.0 1ST SECTION |
| TAP LOCATION TOLERANCE PER SECTION | -250.0 TO 250.0 OHMS 1ST SECTION |
| BODY STYLE | 5B CYLINDRICAL SERVO MOUNTED |
| PILOT DIAMETER | 1.3120 INCHES NOMINAL |
| PILOT LENGTH | 0.1320 INCHES NOMINAL |
| UNDERCUT DIAMETER | 1.315 INCHES MAXIMUM |
| UNDERCUT WIDTH | 0.0730 INCHES MINIMUM |
| BODY DIAMETER | 1.453 INCHES MAXIMUM |
| BODY LENGTH | 1.800 INCHES MAXIMUM |
| MOUNTING LIP DIAMETER | 1.4370 INCHES NOMINAL |
| MOUNTING LIP DEPTH | 0.0930 INCHES NOMINAL |
| ACTUATOR TYPE | SINGLE SHAFT |
| SHAFT STYLE | 1C ROUND |
| SHAFT DIAMETER | 0.125 INCHES MAXIMUM |
| SHAFT LENGTH | 0.672 INCHES NOMINAL |
| ROTARY ACTUATOR TRAVEL IN ANGULAR DEG | 360.0 NOMINAL |
| ACTUATOR TRAVEL CONTROL FEATURE | STOPS |
| EFFECTIVE ELECTRICAL ROTATION IN DEG ANGULAR ROTATION | 350.0 NOMINAL |
| MOUNTING METHOD | CLAMP RING |
Restrictions/Controls & Freight Information | NSN 5905-01-167-6975
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Electro-static Discharge Susceptible: | B | ESD sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 062960 | REOSTATS/PARTS NOI |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | TX | Defense Supply Center Columbus Columbus, OH 43218 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | 3 | Electrostatic Sensitive Device (ESD), subject to damage caused by electrostatic discharge. (See DoD 4500.32-R, Volume 1, Appendix A, Section I for additional information on ESD devices). |
Management | NSN 5905-01-167-6975
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Materiel Management Aggregation Code | EH | SX:ELECTRONIC COMPONENTS |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
