NSN 5895-00-450-1726 631471, 63147-1, 00-450-1726
Product Details | ELECTRONIC COMMAND SIGNALS PROGRAMM SWITCHING UNIT
5895-00-450-1726 An item specifically designed to be used in conjunction with other electronic components to provide automatic switching facilities for a PROGRAMMER, ELECTRONIC COMMAND SIGNALS. For manually operated switching units, see SWITCH (as modified).20314300037Guided Missile Remote Control Systems58950037Miscellaneous Communication Equipment70350021ADP Support Equipment
Part Alternates: 631471, 63147-1, 5895-00-450-1726, 00-450-1726, 5895004501726, 004501726
Communication, Detection, and Coherent Radiation Equipment | Miscellaneous Communication Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 58 | 17 DEC 1969 | 00-450-1726 | 16234 ( SWITCHING UNIT, ELECTRONIC COMMAND SIGNALS PROGRAMMER ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5895-00-450-1726
Technical Data | NSN 5895-00-450-1726
| Characteristic | Specifications |
|---|---|
| SWITCH OPERATION METHOD | MAGNETIC |
| SWITCH ACTION TYPE | ARMATURE RELAY |
| SWITCH POLE QUANTITY | 54 |
| SWITCH POSITION QUANTITY | 2 |
| SWITCH OFF POSITION | NOT INCLUDED |
| CURRENT TYPE | AC |
| VOLTAGE IN VOLTS | 115.0 |
| FREQUENCY RATING | 400.0 HERTZ NOMINAL |
| PHASE | SINGLE |
| CURRENT RATING IN AMPS | 3.0 |
| MANUAL OPERATION FACILITY | NOT PROVIDED |
| OVERALL LENGTH | 15.620 INCHES NOMINAL |
| OVERALL WIDTH | 12.000 INCHES NOMINAL |
| OVERALL DEPTH | 9.000 INCHES NOMINAL |
| MOUNTING CONFIGURATION | RACK MTD |
| III FSC APPLICATION DATA | DETECTING-RANGING SET,SONAR |
| MANUFACTURERS CODE | 9Y580 |
| DESIGN CONTROL REFERENCE | 63147-1 |
Restrictions/Controls & Freight Information | NSN 5895-00-450-1726
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | D | Munitions List Item or Commerce Control List Item. Demilitarization required. Total destruction of the item and components so as to preclude restoration or repair to a usable condition by melting, cutting, tearing, scratching, crushing, breaking, punching, neutralizing, etc. (As an alternate, burial or deep water dumping may be used when coordinated with the DoD Demilitarization Program Office.) |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061300 | CIRCUIT BREAKER/SWITCH NOI |
| Less than car load rating | P | 77.5 |
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 658 | unknown |
| Originating Activity Code | HH | Navy ICP Mechanicsburg, PA 17055-0788 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
