NSN 5365-00-929-5797 51865, 5186-5, 00-929-5797
Product Details | EXTERNALLY THREADED RING
5365-00-929-5797 A cylindrically shaped item with a concentric bore and a peripheral thread over its entire length or over a portion thereof. One face is drilled, slotted, knurled, or has projecting lugs for installation and/or removal purposes. Excludes RETAINER, OPTICAL ELEMENT.202132500005365000000
Part Alternates: 51865, 5186-5, 5365-00-929-5797, 00-929-5797, 5365009295797, 009295797
Hardware and Abrasives | Bushings, Rings, Shims, and Spacers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 09 SEP 1966 | 00-929-5797 | 08417 ( RING, EXTERNALLY THREADED ) |
Cross Reference | NSN 5365-00-929-5797
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 5186-5 | 02121 | GOODRICH AEROSPACE CANADA LTD DBA GOODRICH LANDING GEAR |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5365-00-929-5797
Technical Data | NSN 5365-00-929-5797
| Characteristic | Specifications |
|---|---|
| MATERIAL | ALUMINUM ALLOY |
| SURFACE TREATMENT | ANODIZED |
| OVERALL LENGTH | 0.927 INCHES MINIMUM AND 0.937 INCHES MAXIMUM |
| MATERIAL HARDNESS RATING | NOT RATED |
| CASEHARDENING INDICATOR | NOT CASEHARDENED |
| DRIVE TYPE | SLOTTED FACE |
| ACCOMMODATION TYPE AND QUANTITY | 4 SLOTS |
| WIDTH | 0.260 INCHES NOMINAL |
| DEPTH | 0.200 INCHES NOMINAL |
| ANGLE BETWEEN ACCOMMODATIONS IN DEG | 90.0 |
| THREAD SIZE | 4-1/4 IN.-16 |
| SCREW THREAD SERIES DESIGNATOR | UN |
| THREAD CLASS | 3A |
| THREAD DIRECTION | RIGHT-HAND |
| BEVELED THREAD | NOT INCLUDED |
| THREAD LOCATION | END OPPOSITE DRIVE END |
| BORE SHAPE | TAPERED |
| TAPER MAJOR DIAMETER | 3.875 INCHES NOMINAL |
| TAPER MINOR DIAMETER | 3.550 INCHES NOMINAL |
| TAPER MAJOR DIAMETER LOCATION | DRIVE END |
| BORE ANNULAR INTERNAL SERRATION | NOT INCLUDED |
| BORE EDGE PROCESS | CHAMFERED |
| PROCESS END LOCATION | DRIVE END |
| CHAMFER ANGLE IN DEG | 45.0 |
| CHAMFER LENGTH | 0.060 INCHES NOMINAL |
| SETSCREW LOCKING NOTCH | NOT INCLUDED |
| MANUFACTURERS CODE | 02121 |
| DESIGN CONTROL REFERENCE | 5186-5 |
Restrictions/Controls & Freight Information | NSN 5365-00-929-5797
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 106460 | RINGS ROLLED STEEL NOI |
| Less than car load rating | Q | 70 |
| Less than truck load rating | Q | 70.0 |
| Water commodity Code | 596 | unknown |
| Originating Activity Code | CT | U.S. Army Aviation and Missile Command (AIR) Redstone Arsenal, AL 35898-5230 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | ||
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | Z | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
